NSK BSF3590DDUHP2BDT R BE4L5 2 Row Ball Screw Support Bearing - 35 mm ID, 90 mm OD 64 mm Race Width

View all Ball Bearings

Subtotal (1 pair)*

£478.81

(exc. VAT)

£574.57

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 31 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pair(s)
Per Pair
1 +£478.81

*price indicative

Ballbearings-Seals
Explore our Seals
Looking for Ball Bearings? Don’t Forget the Seals. Ball bearings and seals are a perfect pairing—while bearings reduce friction and support motion, seals help protect them from dust, moisture, and contaminants, extending their lifespan and performance. If you're sourcing ball bearings, it's worth checking out our range of seals to complete your setup. Explore compatible seals to ensure your application runs smoothly and reliably.
Shop Now
RS Stock No.:
134-9095
Mfr. Part No.:
BSF3590DDUHP2BDT R BE4L5
Brand:
NSK
Find similar products by selecting one or more attributes.
Select all

Brand

NSK

Inside Diameter

35 mm

Product Type

Ball Screw Support Bearing

Outside Diameter

90 mm

Race Width

64mm

Cage Material

Steel

Ball Material

Steel

End Type

Sealed

Number of Rows

2

Contact Angle

60°

Static Load Rating

155kN

Dynamic Load Rating

64.5kN

Bore Type

Parallel

Series

BSF

Standards/Approvals

No

Limiting Speed

3800rpm

Bearing Type

Single Row Angular Contact Ball

Race Type

Flanged

Flange Outside Diameter

90mm

Ball Screw Support Bearings - BSF Series


The BSF series of bearings is equivalent to the BSN range of bearings, with an extended outer ring, with bolt holes for easy direct mounting. Relubrication holes in outside surface and face of the outer ring allow for relubrication during operation if necessary. The holes are closed off with set screws. An extraction groove on the outer surface of the outer ring aids removal of the bearing.

BSF-DT Series


The matched DT pairs are essentially the same as the individual bearings. The two individual bearings have been matched together in the paired version. Some sizes also have extra fixing holes in the outer diameter. Both bearings have a V-shaped mark on the outer diameter to ensure that they are arranged correctly.

Features and Benefits


• 60° Contact angle enabling the bearings to support large axial forces

• Double row to support axial force in two directions

• Contact lip seal provides excellent sealing with low friction and heat generation

• Greased for life (under normal operating conditions)

• Easy mounting directly onto machinery

• Extraction groove to aid with removal

• Set screws

Product Application Information


Ideal for use in machine tools.
