SKF 6403-2RS1/C3 1 Row Ball Bearing - 17 mm ID, 62 mm OD
- RS Stock No.:
- 461-369
- Mfr. Part No.:
- 6403-2RS1/C3
- Brand:
- SKF
Subtotal (1 unit)*
£59.67
(exc. VAT)
£71.60
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 03 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £59.67 |
*price indicative
- RS Stock No.:
- 461-369
- Mfr. Part No.:
- 6403-2RS1/C3
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 17mm | |
| Product Type | Ball Bearing | |
| Outside Diameter | 62mm | |
| Race Width | 17mm | |
| Ball Material | Steel | |
| Cage Material | Sheet Metal | |
| End Type | Sealed | |
| Number of Rows | 1 | |
| Static Load Rating | 10.8kN | |
| Internal Clearance | 25 μm | |
| Dynamic Load Rating | 22.9kN | |
| Series | 6403 | |
| Standards/Approvals | No | |
| Bore Type | Cylindrical | |
| Limiting Speed | 8500rpm | |
| Bearing Type | Deep Groove Ball | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 17mm | ||
Product Type Ball Bearing | ||
Outside Diameter 62mm | ||
Race Width 17mm | ||
Ball Material Steel | ||
Cage Material Sheet Metal | ||
End Type Sealed | ||
Number of Rows 1 | ||
Static Load Rating 10.8kN | ||
Internal Clearance 25 μm | ||
Dynamic Load Rating 22.9kN | ||
Series 6403 | ||
Standards/Approvals No | ||
Bore Type Cylindrical | ||
Limiting Speed 8500rpm | ||
Bearing Type Deep Groove Ball | ||
Gavin
The SKF Single row deep groove ball bearings with seals or shields are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types. The integral sealing can significantly prolong bearing service life because it keeps lubricant in the bearings and contaminants out.
Low friction
High speed capability
Accommodate radial and axial loads in both directions
