SKF 3210 A-2Z 2 Row Angular Contact Ball Bearing - 50 mm ID, 90 mm OD 30.2 mm Race Width
- RS Stock No.:
- 461-254
- Mfr. Part No.:
- 3210 A-2Z
- Brand:
- SKF
Subtotal (1 unit)*
£141.07
(exc. VAT)
£169.28
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 02 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £141.07 |
*price indicative
- RS Stock No.:
- 461-254
- Mfr. Part No.:
- 3210 A-2Z
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Angular Contact Ball Bearing | |
| Inside Diameter | 50 mm | |
| Outside Diameter | 90 mm | |
| Race Width | 30.2mm | |
| Ball Material | Bearing Steel | |
| Cage Material | Sheet Metal | |
| Race Material | Bearing Steel | |
| End Type | Double Shielded | |
| Number of Rows | 2 | |
| Contact Angle | 30° | |
| Static Load Rating | 42.5kN | |
| Internal Clearance | CN | |
| Dynamic Load Rating | 51kN | |
| Series | 3210 | |
| Standards/Approvals | RoHS | |
| Limiting Speed | 7000rpm | |
| Bearing Type | Double Row Angular Contact Ball | |
| Race Type | Grooved | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Angular Contact Ball Bearing | ||
Inside Diameter 50 mm | ||
Outside Diameter 90 mm | ||
Race Width 30.2mm | ||
Ball Material Bearing Steel | ||
Cage Material Sheet Metal | ||
Race Material Bearing Steel | ||
End Type Double Shielded | ||
Number of Rows 2 | ||
Contact Angle 30° | ||
Static Load Rating 42.5kN | ||
Internal Clearance CN | ||
Dynamic Load Rating 51kN | ||
Series 3210 | ||
Standards/Approvals RoHS | ||
Limiting Speed 7000rpm | ||
Bearing Type Double Row Angular Contact Ball | ||
Race Type Grooved | ||
- COO (Country of Origin):
- US
Omkar
The SKF Double row angular contact ball bearings, with seals or shields, correspond to a pair of single row angular contact ball bearings in a back-to-back arrangement, while requiring less axial space. Depending on the sealing execution, they can operate at high speeds and are more suitable than deep groove ball bearings for supporting large axial forces in both directions.
Accommodate relatively high radial loads, high axial loads in both directions and tilting moments
Suitable where a stiff bearing arrangement is required
Require less axial space than equivalent pair of single row angular contact ball bearings
