Sanyo Denki San Ace 9S Series Axial Fan, 24 V dc, DC Operation, 50m³/h, 960mW, 40mA Max, 92 x 92 x 25mm

Save 23% when you buy 50 units

Subtotal (1 unit)*

£16.05

(exc. VAT)

£19.26

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 4 unit(s) ready to ship
  • Plus 25 unit(s) ready to ship from another location
  • Plus 999,999,995 unit(s) shipping from 22 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 4£16.05
5 - 9£15.08
10 - 24£14.12
25 - 49£13.49
50 +£12.22

*price indicative

RS Stock No.:
862-1611
Distrelec Article No.:
301-16-845
Mfr. Part No.:
9S0924L4011
Brand:
Sanyo Denki
Find similar products by selecting one or more attributes.
Select all

Brand

Sanyo Denki

Supply Voltage

24 V dc

AC or DC Operation

DC

Height

92mm

Power Consumption

960mW

Width

92mm

Maximum Current

40mA

Depth

25mm

Dimensions

92 x 92 x 25mm

Termination Type

Lead Wire

Air Flow

50m³/h

Noise Level

17dB

Fan Speed

1750rpm

Sensor Type

Tachometer

Bearing Type

Ball

COO (Country of Origin):
PH

San Ace Silent DC Fans - S Series


Sanyo Denki San Ace silent DC fans are the lowest audible noise ball bearing DC fans available, with a reduction of up to -6dB when compared to standard fans. San Ace silent DC fans also feature excellent airflow and static pressure performance due to a new impeller and motor design.

50% reduction in vibration with precision dual ball bearing motor and fan blade balancing
Reduced switching noise at low speed compared to other DC fans
3rd wire pulse sensor for monitoring fan speed as standard
Airflow and noise level specification guaranteed over the life of the fan
Life at 40°C ambient 67,000 hours continuous operation (fan mounted in any position)
ECO product

Approvals

UL, CSA, TUV

Sanyo Denki Axial Fan, 24V DC, 49.8m³/h Air Flow - San Ace 9S Series - 9S0924L4011


Protect your industrial systems from overheating using this axial fan from Sanyo Denki. Its propellers draw in hot air and move it on a parallel axis to cool down your equipment. A fast rotating speed of 1750rpm and a maximum air flow of 49.8m³/h ensure effective cooling. The built-in ball bearing maintains a balanced rotation to keep the unit from vibrating, helping to reduce noise and mechanical wear.

Features & Benefits


• Minimal noise level of 17dB for quiet operation
• Wide operating temperature range between -10°C and +70°C for use in demanding environments
• Compact dimensions of 92 (height) x 92 (width) x 25mm (depth) to fit in small spaces
• Long service life of 40,000 hours for robust performance

Applications


• Data centres
• Aviation industry
• HVAC systems
• Server cabinets

What's the difference between a DC and an AC axial fan?


While a DC axial fan is typically powered by a stable power supply like a battery pack, an AC version is powered by a line current. DC fans also generally consume less power than their AC counterparts.
