Sunon Axial Fan, 12 V dc, dc Operation, 5.5cfm, 0.66/0.77W, 64mA Max, 30 x 30 x 10mm

View all Axial Fans

Subtotal (1 unit)*

£13.33

(exc. VAT)

£16.00

(inc. VAT)

Add to Basket
Select or type quantity
Last RS stock
  • Final 192 unit(s), ready to ship from another location
Units
Per unit
1 +£13.33

*price indicative

RS Stock No.:
288-4896
Distrelec Article No.:
301-34-001
Mfr. Part No.:
MF30101V1-1000U-G99
Brand:
Sunon
Find similar products by selecting one or more attributes.
Select all

Brand

Sunon

Supply Voltage

12 V dc

Height

30mm

AC or DC Operation

dc

Width

30mm

Power Consumption

0.66/0.77W

Maximum Current

64mA

Depth

10mm

Dimensions

30 x 30 x 10mm

Air Flow

5.5cfm

COO (Country of Origin):
CN
The MagLev Motor Fan measures 30x30x10 mm, making it ideal for small spaces. With a single phase, 4-poles Brushless DC motor design and precise Vapo bearing system, this fan offers reliable performance. The thermoplastic PBT frame and fan blade materials are UL 94V-0 rated for safety. It operates at a rated voltage of 12 VDC, with a rated current of 55mA and a rated power consumption of 0.66 WATTS. The fan provides an air flow of 5.5 CFM and a static pressure of 0.25 Inch-H2O. With a life expectancy of 70,000 hours at 40°C, 65% humidity, and 90% CL, this fan is built to last.

Compact size of 30x30x10 mm for easy installation in small spaces
Single phase, 4-poles Brushless DC motor design for reliable performance
Precise Vapo bearing system for smooth and quiet operation
Thermoplastic PBT frame and fan blade materials with UL 94V-0 rating for safety
Rated voltage of 12 VDC, rated current of 55mA, and rated power consumption of 0.66 WATTS
Air flow of 5.5 CFM and static pressure of 0.25 Inch-H2O for efficient cooling
70,000 hours life expectancy at 40°C, 65% humidity, and 90% CL for long-lasting operation
