ABB Auxiliary Contact, 4 Contact, 3 NO/1 NC, CA4, Front, 6 A, 690V ac, 1SBN010140R1031 CA4-31E
- RS Stock No.:
- 711-6357
- Mfr. Part No.:
- 1SBN010140R1031 CA4-31E
- Brand:
- ABB
Subtotal (1 unit)*
£19.19
(exc. VAT)
£23.03
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 29 unit(s) shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £19.19 |
*price indicative
- RS Stock No.:
- 711-6357
- Mfr. Part No.:
- 1SBN010140R1031 CA4-31E
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Product Type | Auxiliary Contact | |
| Number of Contacts | 4 | |
| Normal State Configuration | 3 NO/1 NC | |
| Series | CA4 | |
| Contact Current | 6A | |
| Mount Type | Front | |
| Terminal Type | Screw | |
| Pole and Throw Configuration | 4 | |
| Contact Voltage | 690V ac | |
| Operational Current Ie | 6A | |
| Mechanical Durability | 10Mcycles | |
| Rated Insulation Voltage Ui | 690V | |
| Minimum Operating Temperature | -40°C | |
| Mounting Location | Front Side | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand ABB | ||
Product Type Auxiliary Contact | ||
Number of Contacts 4 | ||
Normal State Configuration 3 NO/1 NC | ||
Series CA4 | ||
Contact Current 6A | ||
Mount Type Front | ||
Terminal Type Screw | ||
Pole and Throw Configuration 4 | ||
Contact Voltage 690V ac | ||
Operational Current Ie 6A | ||
Mechanical Durability 10Mcycles | ||
Rated Insulation Voltage Ui 690V | ||
Minimum Operating Temperature -40°C | ||
Mounting Location Front Side | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals No | ||
ABB CA4 Series Auxiliary Contact, 6A Contact Current, 690V Contact Voltage - 1SBN010140R1031 CA4-31E
This auxiliary contact provides additional switching logic when fitted to compatible contactors and mounts to the front side for convenient access in control panels. It integrates instantaneous auxiliary contacts with screw terminals and is designed for standard industrial environments where compact, front-mounted signalling or interlocking is required.
Features & Benefits
• 3NO and 1NC instantaneous contacts offering versatile signalling
• 6A operational current for switching control circuits at rated voltages
• 690V rated insulation supporting higher-voltage auxiliary circuits
• Mechanical endurance of 10M cycles for long service life
• Operates from −40°C to 70°C for wide environmental tolerance
• Screw Terminal connections for secure conductor termination
• 6A operational current for switching control circuits at rated voltages
• 690V rated insulation supporting higher-voltage auxiliary circuits
• Mechanical endurance of 10M cycles for long service life
• Operates from −40°C to 70°C for wide environmental tolerance
• Screw Terminal connections for secure conductor termination
**Applications**
• Suitable for expansion of AF09–AF96 contactor control circuits
• Used for status feedback to PLCs and control relays
• Ideal for interlocking contactor arrangements in motor control
• Used with AFC and AF series contactors for retrofit replacements
• Suitable for factory automation panel signalling functions
• Used for status feedback to PLCs and control relays
• Ideal for interlocking contactor arrangements in motor control
• Used with AFC and AF series contactors for retrofit replacements
• Suitable for factory automation panel signalling functions
How is the unit mounted for retrofits into existing contactor assemblies?
It attaches to the front face of compatible contactors, matching Terminal arrangements for the AF and AFC families to enable straightforward replacement without panel rework.
What conductor sizes can be terminated reliably at the terminals?
Connecting capacity accommodates rigid and flexible conductors from 1 x 0.75 mm² up to 2.5 mm² and insulated ferrules as specified for secure clamping.
What electrical stress ratings apply for impulse and short-time withstand?
The device has a rated impulse withstand voltage of 6 kV and specified short-time withstand currents for brief fault conditions as per auxiliary circuit ratings.
How does switching frequency affect suitability for high-cycle applications?
Maximum electrical switching frequency supports up to several hundred cycles per hour depending on AC/DC duty, while mechanical switching capability reaches many thousands of cycles to match intensive use.
Standards
UL 508, CSA C22.2 N14
