Delphi GT 150 Series, 1 Row 12 Way Cable Mount Socket Connector, with Crimp Termination Method

  • RS Stock No. 896-1855
  • Mfr. Part No. 12191905
  • Brand Delphi
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): US
Product Details

Delphi GT150 Sealed Female Automotive Connectors

The Delphi GT150 series of sealed female automotive connectors have a 1.5mm blade width.These automotive connectors have silver interface platings which pass the SAE ® J2030 Heavy Duty Connector standard.The connectors have a maximum current capacity of 15 Amps and a temperature range of -40°C -125°C.

Delphi GT150 Series Automotive Connectors

Specifications
Attribute Value
Number of Contacts 12
Type Connector
Gender Female
Number of Rows 1
Current Rating 15A
Mounting Type Cable Mount
Series GT 150
Colour Black
Termination Method Crimp
Height 19.5mm
Width 65.1mm
Depth 37.6mm
Maximum Operating Temperature +125°C
Contact Plating Tin
Contact Material Tin Brass
Housing Material PA 72
Minimum Operating Temperature -40°C
20 In stock for FREE next working day delivery
Price Each (In a Pack of 10)
£ 1.529
(exc. VAT)
£ 1.835
(inc. VAT)
Units
Per unit
Per Pack*
10 - 90
£1.529
£15.29
100 - 240
£0.873
£8.73
250 - 490
£0.786
£7.86
500 - 990
£0.708
£7.08
1000 +
£0.637
£6.37
*price indicative
