JAE, MX34 Automotive Connector Socket Grey Cable Mount 3 Way MX34003SF1

View all Automotive Connectors
Bulk discount available

Subtotal (1 unit)*

£0.71

(exc. VAT)

£0.85

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 62 unit(s) ready to ship
  • Plus 3 unit(s) ready to ship from another location
  • Plus 1,457 unit(s) shipping from 10 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 9£0.71
10 - 99£0.65
100 +£0.59

*price indicative

Packaging Options:
Automotive-Connector-Backshells
Automotive Connector Backshells
Don't forget Automotive Connector Backshells!
Shop now
RS Stock No.:
690-9883
Mfr. Part No.:
MX34003SF1
Brand:
JAE
Find similar products by selecting one or more attributes.
Select all

Brand

JAE

Type

Socket Housing

Number of Contacts

3

Gender

Female

Number of Rows

1

Current Rating

3A

Mounting Type

Cable Mount

Series

MX34

Colour

Grey

Height

12.2mm

Width

10.8mm

Housing Material

Nylon, PPE

Depth

21.3mm

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

+85°C

MX34 Socket Housing 1 Row


For MX34 contacts see typical stock number 690-9893
For MX34 headers see typical stock numbers: 690-8957 (Straight) or 690-8929 (90°)


JAE MX34 Series Automotive Connectors


The MX34 series connectors are compact, non-waterproof board-to-cable connectors, and are developed for automotive use.,The up to 40 poles reduces mating and unmating force to 80N or less and improves workability. Furthermore, automotive connector requirements such as the preset type of double locking mechanism and box type of pin header are satisfied


Socket contact with box-type pin header provides a durable combination to external forces
Contacts are highly resistant to twisting and equipped with a proven double leaf spring
The preset-type retainer needs to be completely inserted into the housing for the connector to be engaged, therefore any incomplete contact insertion is detected
The Lock spring is equipped with a bridge which protects the contact from external load
