Amphenol Industrial, ATP Automotive Connector Plug Grey Cable Mount 4 Way, Crimp Termination ATP06-4S
- RS Stock No.:
- 174-1481
- Mfr. Part No.:
- ATP06-4S
- Brand:
- Amphenol Industrial
Subtotal (1 pack of 550 units)*
£940.50
(exc. VAT)
£1,127.50
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 09 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
550 + | £1.71 | £940.50 |
*price indicative
- RS Stock No.:
- 174-1481
- Mfr. Part No.:
- ATP06-4S
- Brand:
- Amphenol Industrial
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Amphenol Industrial | |
Number of Contacts | 4 | |
Type | Automotive Connector | |
Gender | Male | |
Number of Rows | 2 | |
Current Rating | 25A | |
Mounting Type | Cable Mount | |
Series | ATP | |
Colour | Grey | |
Termination Method | Crimp | |
IP Rating | IP67 | |
Height | 27mm | |
Width | 22mm | |
Depth | 34.9mm | |
Housing Material | Thermoplastic | |
Minimum Operating Temperature | -55°C | |
Maximum Operating Temperature | +125°C | |
Corded | Yes | |
Series Number | 06 | |
Select all | ||
---|---|---|
Brand Amphenol Industrial | ||
Number of Contacts 4 | ||
Type Automotive Connector | ||
Gender Male | ||
Number of Rows 2 | ||
Current Rating 25A | ||
Mounting Type Cable Mount | ||
Series ATP | ||
Colour Grey | ||
Termination Method Crimp | ||
IP Rating IP67 | ||
Height 27mm | ||
Width 22mm | ||
Depth 34.9mm | ||
Housing Material Thermoplastic | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature +125°C | ||
Corded Yes | ||
Series Number 06 | ||
Amphenol A Series have key placement in all areas of Heavy Duty Equipment, Agriculture, Marine, Automotive, Military, Alternative Energy and other demanding interconnect applications.
The Amphenol Panel Mate Series combines flange mounting options with the proven reliablity of the AT/ATP Series Environmentally-sealed thermoplastic connection system. Engineered with a one piece sealed flange design for rapid and secure mounting, Its durable high temperature silicone facial Seal provides a barrier of protection from lubricating oils, hydraulic fluids and fossil fuels to withstand the challenges and complexities of harsh environment applications.
10-14 AWG, 25A, Size 12.
High-performance, cost-effective
Superior environmental seal retention capabilities
Compatible with existing standard products industry-wide
High-performance, cost-effective
Superior environmental seal retention capabilities
Compatible with existing standard products industry-wide
