RS PRO Analogue Panel Ammeter 10A AC, 68mm x 68mm, ±1.5 % Moving Iron
- RS Stock No.:
- 901-0346
- Brand:
- RS PRO
Unavailable
RS will no longer stock this product.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£15.70
(exc. VAT)
£18.84
(inc. VAT)
- RS Stock No.:
- 901-0346
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Maximum Value | 10A | |
| Current Type | AC | |
| Moving Element | Moving Iron | |
| Cutout Height | 68mm | |
| Cutout Width | 68mm | |
| Depth | 36.5mm | |
| Meter Accuracy | ±1.5 % | |
| Minimum Temperature | -25°C | |
| Maximum Temperature | +50°C | |
| Measurement Range | 0 → 20A | |
| Minimum Displayed Value | 0A | |
| Series | RS PRO | |
| Approvals | CE, RoHS Compliant, TUV Certified, UL E327849 | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Maximum Value 10A | ||
Current Type AC | ||
Moving Element Moving Iron | ||
Cutout Height 68mm | ||
Cutout Width 68mm | ||
Depth 36.5mm | ||
Meter Accuracy ±1.5 % | ||
Minimum Temperature -25°C | ||
Maximum Temperature +50°C | ||
Measurement Range 0 → 20A | ||
Minimum Displayed Value 0A | ||
Series RS PRO | ||
Approvals CE, RoHS Compliant, TUV Certified, UL E327849 | ||
- COO (Country of Origin):
- TW
RS PRO Analogue Panel Ammeter 10 A AC, 68 mm x 68 mm, ±1.5% Moving Iron
Use this RS PRO analogue panel ammeter to determine the current level in your electrical circuits. It's designed to display the AC current to a high degree of accuracy with a margin of error of only 1.5%.
This ammeter comes fitted with a durable polycarbonate and ABS (acrylonitrile butadiene styrene) thermoplastic housing that's tough enough to withstand knocks and scrapes for a longer product life. The display is clear and quick to read, as it's written in bold black type against a white backdrop.
The display on this ammeter also features a bright red danger zone indicator, so you can see at a glance if the amperage is too high. You'll find ammeters of this kind used in industrial settings such as electronics manufacturing facilities, power plants and telecommunications exchanges.
This ammeter comes fitted with a durable polycarbonate and ABS (acrylonitrile butadiene styrene) thermoplastic housing that's tough enough to withstand knocks and scrapes for a longer product life. The display is clear and quick to read, as it's written in bold black type against a white backdrop.
The display on this ammeter also features a bright red danger zone indicator, so you can see at a glance if the amperage is too high. You'll find ammeters of this kind used in industrial settings such as electronics manufacturing facilities, power plants and telecommunications exchanges.
Features and Benefits
- CE (Conformité Européenne), RoHS (Restriction of Hazardous Substances) compliant, TUV (German Equipment and Product Safety Act) certified, UL (Underwriters' Laboratories) E327849 approvals
- AC current type
- Cutout height of 68 mm
- Cutout width of 68 mm
- Depth of 36.5 mm
- Analogue display type
- Measurement range of 0 to 20 A
- Meter accuracy of ±1.5%
- Maximum operating temperature of +50°C
- Minimum operating temperature of -25°C
- Moving iron element
