Nichicon 6800μF Aluminium Electrolytic Capacitor 50V dc, Snap-In - LGU1H682MELA

RS Stock No.:: 846-6953
Mfr. Part No.:: LGU1H682MELA
Brand:: Nichicon

Nichicon 6800μF Aluminium Electrolytic Capacitor 50V dc, Snap-In - LGU1H682MELA

56 In stock - FREE next working day delivery available

Added

Price Each

£3.39

(exc. VAT)

£4.07

(inc. VAT)

Units	Per unit
1 - 9	£3.39
10 - 24	£3.06
25 - 99	£2.92
100 - 249	£2.32
250 +	£2.20

RS Stock No.:: 846-6953
Mfr. Part No.:: LGU1H682MELA
Brand:: Nichicon

Technical Reference

GU Series Snap-in Terminal Data Sheet

Legislation and Compliance

COO (Country of Origin):: MY

Product Details

Aluminium Electrolytic Capacitors GU Series 105°C

Nichicon GU Series Snap-In Aluminium Electrolytic Capacitors can withstand 3000 hours of rated ripple current application. The snap-in terminal GU Series Aluminium Electrolytic Capacitors from Nichicon offer a large capacitance range with voltages ranging from 16 to 450V. These high performance capacitors have a wide temperature range which is ideal for applications such as uninterruptible power supplies, electric pump motors, and AC servomotors.

Snap-In terminals
Endurance rating ripple current 3000 hours guaranteed
PET sleeve (non PVC)
Lead-free terminal plating

Specifications

Attribute	Value
Capacitance	6800µF
Voltage	50V dc
Mounting Type	Snap-In
Technology	Aluminium Electrolytic
Dimensions	25 (Dia.) x 45mm
Height	45mm
Minimum Operating Temperature	-40°C
Diameter	25mm
Maximum Operating Temperature	+105°C
Lifetime	3000h
Lead Pitch	10mm
Leakage Current	1.74 mA
Ripple Current	3.37A
Tolerance	±20%
Series	GU
