Wurth Elektronik 270μF Aluminium Electrolytic Capacitor 35V dc, Radial, Through Hole - 860080575013
- RS Stock No.:
- 840-0433
- Mfr. Part No.:
- 860080575013
- Brand:
- Wurth Elektronik
470 In stock - FREE next working day delivery available
Added
Price Each (In a Bag of 10)
£0.413
(exc. VAT)
£0.496
(inc. VAT)
| Units | Per unit | Per Bag* |
| 10 - 90 | £0.413 | £4.13 |
| 100 - 190 | £0.298 | £2.98 |
| 200 - 490 | £0.285 | £2.85 |
| 500 + | £0.237 | £2.37 |
| *price indicative | ||
- RS Stock No.:
- 840-0433
- Mfr. Part No.:
- 860080575013
- Brand:
- Wurth Elektronik
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Wurth Elektronik Low Impedance WCAP-ATLI Capacitor Series, 1μF - 270μF
WCAP- ATLI are Low Impedance Aluminium Electrolytic Capacitor Series
Load life: 2000h – 5000h @ +105°C
Operating temperature: -55°C to +105°C
Wave soldering recommended
Load life: 2000h – 5000h @ +105°C
Operating temperature: -55°C to +105°C
Wave soldering recommended
Specifications
Attribute | Value |
|---|---|
| Capacitance | 270µF |
| Voltage | 35V dc |
| Mounting Type | Radial, Through Hole |
| Technology | Aluminium Electrolytic |
| Dimensions | 10 (Dia.) x 16mm |
| Height | 16mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 5000h |
| Lead Pitch | 5mm |
| Leakage Current | 94.5 μA |
| Tolerance | ±20% |
| Ripple Current | 1.19A |
| Series | WCAP-ATLI |
| Dissipation Factor | 9 |
