Wurth Elektronik 3300μF Aluminium Electrolytic Capacitor 50V dc, Radial, Through Hole - 860020681032
- RS Stock No.:
- 839-8709
- Distrelec Article No.:
- 302-96-513
- Mfr. Part No.:
- 860020681032
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 unit)*
£4.62
(exc. VAT)
£5.54
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 74 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
| Units | Per unit |
|---|---|
| 1 - 24 | £4.62 |
| 25 - 49 | £4.30 |
| 50 - 99 | £3.93 |
| 100 - 249 | £3.67 |
| 250 + | £3.33 |
*price indicative
- RS Stock No.:
- 839-8709
- Distrelec Article No.:
- 302-96-513
- Mfr. Part No.:
- 860020681032
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
| Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Capacitance | 3300µF | |
| Voltage | 50V dc | |
| Mounting Type | Radial, Through Hole | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 18 (Dia.) x 35.5mm | |
| Height | 35.5mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 18mm | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 7.5mm | |
| Lifetime | 2000h | |
| Ripple Current | 1.75A | |
| Series | WCAP-ATG5 | |
| Tolerance | ±20% | |
| Leakage Current | 1650 μA | |
| Dissipation Factor | 10 | |
| Select all | ||
|---|---|---|
| Brand Wurth Elektronik | ||
| Capacitance 3300µF | ||
| Voltage 50V dc | ||
| Mounting Type Radial, Through Hole | ||
| Technology Aluminium Electrolytic | ||
| Dimensions 18 (Dia.) x 35.5mm | ||
| Height 35.5mm | ||
| Minimum Operating Temperature -40°C | ||
| Diameter 18mm | ||
| Maximum Operating Temperature +105°C | ||
| Lead Pitch 7.5mm | ||
| Lifetime 2000h | ||
| Ripple Current 1.75A | ||
| Series WCAP-ATG5 | ||
| Tolerance ±20% | ||
| Leakage Current 1650 μA | ||
| Dissipation Factor 10 | ||
Wurth Elektronik WCAP-ATG5 Series 105°C, 390μF- 2000μF
WCAP-ATG5 Aluminium Electrolytic Capacitor series
High temperature, +105°C general purpose product series
Load life: 2000h @ +105°C
Reflow soldering recommended
Operating temperature: -40°C to +105°C for UR < 400 V
-25 °C to +105°C for UR ≥ 400 V
High temperature, +105°C general purpose product series
Load life: 2000h @ +105°C
Reflow soldering recommended
Operating temperature: -40°C to +105°C for UR < 400 V
-25 °C to +105°C for UR ≥ 400 V
