Wurth Elektronik 220μF Aluminium Electrolytic Capacitor 50V dc, Surface Mount - 865060657012
- RS Stock No.:
- 839-5643
- Mfr. Part No.:
- 865060657012
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 pack of 5 units)*
£5.25
(exc. VAT)
£6.30
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 15 unit(s) ready to ship
- Plus 25 unit(s) ready to ship from another location
- Plus 180 unit(s) shipping from 13 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 20 | £1.05 | £5.25 |
| 25 - 45 | £0.998 | £4.99 |
| 50 - 95 | £0.878 | £4.39 |
| 100 - 495 | £0.762 | £3.81 |
| 500 + | £0.598 | £2.99 |
*price indicative
- RS Stock No.:
- 839-5643
- Mfr. Part No.:
- 865060657012
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Capacitance | 220µF | |
| Voltage | 50V dc | |
| Mounting Type | Surface Mount | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 10.5 (Dia.) x 9.85mm | |
| Height | 9.85mm | |
| Minimum Operating Temperature | -55°C | |
| Diameter | 10.5mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 5000h | |
| Lead Pitch | 4.5mm | |
| Polarised | Polar | |
| Series | WCAP-ASLL | |
| Tolerance | ±20% | |
| Ripple Current | 600mA | |
| Leakage Current | 110 μA | |
| Dissipation Factor | 12 | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Capacitance 220µF | ||
Voltage 50V dc | ||
Mounting Type Surface Mount | ||
Technology Aluminium Electrolytic | ||
Dimensions 10.5 (Dia.) x 9.85mm | ||
Height 9.85mm | ||
Minimum Operating Temperature -55°C | ||
Diameter 10.5mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 5000h | ||
Lead Pitch 4.5mm | ||
Polarised Polar | ||
Series WCAP-ASLL | ||
Tolerance ±20% | ||
Ripple Current 600mA | ||
Leakage Current 110 μA | ||
Dissipation Factor 12 | ||
Wurth Elektronik SMD Low Impedance, Long Life WCAP-ASLL Capacitor Series
WCAP-ASLL are low impedance long life Aluminium Electrolytic Capacitor Series
Features and Benefits
• Load life: 2000 h – 5000 h @ +105°C
• Operating temperature: -55°C to +105°C
• Reflow soldering recommended
• Operating temperature: -55°C to +105°C
• Reflow soldering recommended
