Wurth Elektronik 100μF Aluminium Electrolytic Capacitor 50V dc, Surface Mount - 865060653010
- RS Stock No.:
- 839-5630
- Mfr. Part No.:
- 865060653010
- Brand:
- Wurth Elektronik
595 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 5)
£0.552
(exc. VAT)
£0.662
(inc. VAT)
| Units | Per unit | Per Pack* |
| 5 - 20 | £0.552 | £2.76 |
| 25 - 45 | £0.524 | £2.62 |
| 50 - 95 | £0.456 | £2.28 |
| 100 - 495 | £0.392 | £1.96 |
| 500 + | £0.306 | £1.53 |
| *price indicative | ||
- RS Stock No.:
- 839-5630
- Mfr. Part No.:
- 865060653010
- Brand:
- Wurth Elektronik
Technical Reference
Legislation and Compliance
Product Details
Wurth Elektronik SMD Low Impedance, Long Life WCAP-ASLL Capacitor Series
WCAP-ASLL are low impedance long life Aluminium Electrolytic Capacitor Series
Features and Benefits
• Load life: 2000 h – 5000 h @ +105°C
• Operating temperature: -55°C to +105°C
• Reflow soldering recommended
• Operating temperature: -55°C to +105°C
• Reflow soldering recommended
Specifications
Attribute | Value |
|---|---|
| Capacitance | 100µF |
| Voltage | 50V dc |
| Mounting Type | Surface Mount |
| Technology | Aluminium Electrolytic |
| Dimensions | 10.5 (Dia.) x 7.85mm |
| Height | 7.85mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 10.5mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 3.1mm |
| Lifetime | 5000h |
| Tolerance | ±20% |
| Series | WCAP-ASLL |
| Polarised | Polar |
| Leakage Current | 50 μA |
| Ripple Current | 350mA |
| Dissipation Factor | 12 |
