Wurth Elektronik 270μF Aluminium Electrolytic Capacitor 16V dc, Radial, Through Hole - 860160374019
- RS Stock No.:
- 839-4347
- Mfr. Part No.:
- 860160374019
- Brand:
- Wurth Elektronik
Available to back order for despatch 08/10/2024
Added
Price Each (In a Pack of 10)
£0.28
(exc. VAT)
£0.34
(inc. VAT)
| Units | Per unit | Per Pack* |
| 10 - 40 | £0.28 | £2.80 |
| 50 - 90 | £0.24 | £2.40 |
| 100 - 190 | £0.20 | £2.00 |
| 200 - 990 | £0.191 | £1.91 |
| 1000 + | £0.16 | £1.60 |
| *price indicative | ||
- RS Stock No.:
- 839-4347
- Mfr. Part No.:
- 860160374019
- Brand:
- Wurth Elektronik
Technical Reference
Legislation and Compliance
Product Details
Wurth Elektronik WCAP-ATLL Series 105°C, 0.1μF- 330μF 105°C
WCAP-ATLL are long life Aluminum Electrolytic Capacitors
Features and Benefits
• Load life: 3000-10000h @+105°C
• Low impedance and high temperature product series
• Operating Temperature: -55°C to +105°C
• Wave Soldering recommended
• Low impedance and high temperature product series
• Operating Temperature: -55°C to +105°C
• Wave Soldering recommended
Specifications
Attribute | Value |
|---|---|
| Capacitance | 270µF |
| Voltage | 16V dc |
| Mounting Type | Radial, Through Hole |
| Technology | Aluminium Electrolytic |
| Dimensions | 8 (Dia.) x 11.5mm |
| Height | 11.5mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 8mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 7000h |
| Lead Pitch | 3mm |
| Series | WCAP-ATLL |
| Leakage Current | 43.2 μA |
| Ripple Current | 582mA |
| Tolerance | ±20% |
| Dissipation Factor | 16 |
