EPCOS 0.22F Aluminium Electrolytic Capacitor 40V dc, Screw Terminal - B41560A7220M600
- RS Stock No.:
- 773-4321
- Mfr. Part No.:
- B41560A7220M600
- Brand:
- EPCOS
Bulk discount available
Subtotal (1 unit)*
£91.17
(exc. VAT)
£109.40
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 12 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £91.17 |
| 5 - 9 | £85.70 |
| 10 - 24 | £80.23 |
| 25 + | £74.76 |
*price indicative
- RS Stock No.:
- 773-4321
- Mfr. Part No.:
- B41560A7220M600
- Brand:
- EPCOS
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | EPCOS | |
| Capacitance | 0.22F | |
| Voltage | 40V dc | |
| Mounting Type | Screw Terminal | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 76.9 x 143.2mm | |
| Height | 143.2mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 76.9mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 3000h | |
| Lead Pitch | 31.7mm | |
| Series | B41560 | |
| Tolerance | ±20% | |
| Leakage Current | ≤0.018 μA (Cr/μF x Vr/V)^0.85 + 4 μA | |
| Ripple Current | 34A | |
| Equivalent Series Resistance | 5mΩ | |
Select all | ||
|---|---|---|
Brand EPCOS | ||
Capacitance 0.22F | ||
Voltage 40V dc | ||
Mounting Type Screw Terminal | ||
Technology Aluminium Electrolytic | ||
Dimensions 76.9 x 143.2mm | ||
Height 143.2mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 76.9mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 3000h | ||
Lead Pitch 31.7mm | ||
Series B41560 | ||
Tolerance ±20% | ||
Leakage Current ≤0.018 μA (Cr/μF x Vr/V)^0.85 + 4 μA | ||
Ripple Current 34A | ||
Equivalent Series Resistance 5mΩ | ||
B41560 Series
Ideal for computer power supply applications or other applications that require long operational life
Long-life grade capacitors
Extremely compact
High ripple current capability
Long-life grade capacitors
Extremely compact
High ripple current capability
