Vishay 470 μF Capacitor 250V dc, Through Hole - MAL215933471E3
- RS Stock No.:
- 280-6783
- Mfr. Part No.:
- MAL215933471E3
- Brand:
- Vishay
Subtotal (1 box of 100 units)*
£605.00
(exc. VAT)
£726.00
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 200 unit(s) shipping from 23 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 100 + | £6.05 | £605.00 |
*price indicative
- RS Stock No.:
- 280-6783
- Mfr. Part No.:
- MAL215933471E3
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Product Type | Capacitor | |
| Capacitance | 470μF | |
| Voltage | 250V dc | |
| Construction | Cylindrical Can | |
| Mount Type | Through Hole | |
| Packaging | Cardboard Box | |
| Polarity | Polar | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 25mm | |
| Termination Type | Snap-In | |
| Capacitor Ripple Current | 1.6A | |
| Pin Count | 3 | |
| Maximum Operating Temperature | 105°C | |
| Lifetime | 5000 h | |
| Standards/Approvals | CECC 30301, IEC 60068, IEC 60384-4/EN 130300 | |
| Series | 159 PUL-SI | |
| Automotive Standard | No | |
| Equivalent Series Resistance ESR | 270mΩ | |
| Tolerance | ±20 % | |
| Leakage Current | 1.2mA | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Product Type Capacitor | ||
Capacitance 470μF | ||
Voltage 250V dc | ||
Construction Cylindrical Can | ||
Mount Type Through Hole | ||
Packaging Cardboard Box | ||
Polarity Polar | ||
Minimum Operating Temperature -25°C | ||
Diameter 25mm | ||
Termination Type Snap-In | ||
Capacitor Ripple Current 1.6A | ||
Pin Count 3 | ||
Maximum Operating Temperature 105°C | ||
Lifetime 5000 h | ||
Standards/Approvals CECC 30301, IEC 60068, IEC 60384-4/EN 130300 | ||
Series 159 PUL-SI | ||
Automotive Standard No | ||
Equivalent Series Resistance ESR 270mΩ | ||
Tolerance ±20 % | ||
Leakage Current 1.2mA | ||
The Vishay aluminium electrolytic capacitor has power ultra long life snap in terminals. It is used for general purpose, industrial and audio or video systems applications, it has low ESR and high ripple current capability.
High reliability
Long life and insulated
