Nichicon 47 μF Capacitor 500V dc, Radial, Through Hole - UCY2H470MHD6 Radial Lead
- RS Stock No.:
- 243-7276
- Mfr. Part No.:
- UCY2H470MHD6
- Brand:
- Nichicon
Subtotal (50 units, in packs of 50)*
£134.40
(exc. VAT)
£161.30
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 19 July 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 50 + | £2.688 | £134.40 |
*price indicative
- RS Stock No.:
- 243-7276
- Mfr. Part No.:
- UCY2H470MHD6
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Nichicon | |
| Product Type | Capacitor | |
| Capacitance | 47μF | |
| Voltage | 500V dc | |
| Mount Type | Radial, Through Hole | |
| Construction | Radial Can | |
| Packaging | Tape | |
| Length | 31.5mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 18mm | |
| Pin Count | 2 | |
| Capacitor Ripple Current | 440mA | |
| Termination Type | Radial Lead | |
| Maximum Operating Temperature | 105°C | |
| Lifetime | 10000 h | |
| Lead Pitch | 7.5mm | |
| Standards/Approvals | RoHS | |
| Series | UCY | |
| Tolerance | ±20 % | |
| Leakage Current | 1mA | |
| Automotive Standard | AEC-Q200 | |
| Dissipation Factor | 24% | |
| Select all | ||
|---|---|---|
Brand Nichicon | ||
Product Type Capacitor | ||
Capacitance 47μF | ||
Voltage 500V dc | ||
Mount Type Radial, Through Hole | ||
Construction Radial Can | ||
Packaging Tape | ||
Length 31.5mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 18mm | ||
Pin Count 2 | ||
Capacitor Ripple Current 440mA | ||
Termination Type Radial Lead | ||
Maximum Operating Temperature 105°C | ||
Lifetime 10000 h | ||
Lead Pitch 7.5mm | ||
Standards/Approvals RoHS | ||
Series UCY | ||
Tolerance ±20 % | ||
Leakage Current 1mA | ||
Automotive Standard AEC-Q200 | ||
Dissipation Factor 24% | ||
- COO (Country of Origin):
- JP
The Nichicon's UCY series is miniature size aluminium capacitor have high ripple current and high reliability.
High ripple current and Long Life product withstanding load life of 10000 to 12000 hours at +105°C
Suited for power supply and ballast application
Compliant to the RoHS directive (2011/65/EU,(EU) 2015/863)
AEC-Q200 compliant
