Panasonic 220μF Aluminium Electrolytic Aluminium Electrolytic Capacitor 16V dc, Radial, Through Hole - EEUFR1C221B
- RS Stock No.:
- 240-3873
- Mfr. Part No.:
- EEUFR1C221B
- Brand:
- Panasonic
Subtotal (1 tape of 2000 units)*
£144.00
(exc. VAT)
£172.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 24,000 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 2000 + | £0.072 | £144.00 |
*price indicative
- RS Stock No.:
- 240-3873
- Mfr. Part No.:
- EEUFR1C221B
- Brand:
- Panasonic
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Capacitance | 220µF | |
| Voltage | 16V dc | |
| Mounting Type | Radial, Through Hole | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 6.3 x 11.2mm | |
| Length | 11.2mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 6.3mm | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 5mm | |
| Leakage Current | 35.2 μA | |
| Polarised | Polar | |
| Ripple Current | 455mA | |
| Tolerance | ±20% | |
| Series | FR-A | |
| Dissipation Factor | 200% | |
Select all | ||
|---|---|---|
Brand Panasonic | ||
Capacitance 220µF | ||
Voltage 16V dc | ||
Mounting Type Radial, Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 6.3 x 11.2mm | ||
Length 11.2mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 6.3mm | ||
Maximum Operating Temperature +105°C | ||
Lead Pitch 5mm | ||
Leakage Current 35.2 μA | ||
Polarised Polar | ||
Ripple Current 455mA | ||
Tolerance ±20% | ||
Series FR-A | ||
Dissipation Factor 200% | ||
