Nichicon 470μF Aluminium Electrolytic Capacitor 50V dc, Radial, Through Hole - UPW1H471MHD1TO
- RS Stock No.:
- 222-9625
- Mfr. Part No.:
- UPW1H471MHD1TO
- Brand:
- Nichicon
2000 In stock - FREE next working day delivery available
Added
Price Each (On a Tape of 500)
£0.563
(exc. VAT)
£0.676
(inc. VAT)
| Units | Per unit | Per Tape* |
| 500 + | £0.563 | £281.50 |
| *price indicative | ||
- RS Stock No.:
- 222-9625
- Mfr. Part No.:
- UPW1H471MHD1TO
- Brand:
- Nichicon
Technical Reference
Legislation and Compliance
Product Details
The Nichicon UPW series is a Lead type aluminium electrolytic capacitor which have rated capacitance of 470 μF with capacitance tolerance of ± 20% and also has low impedance and high reliability withstanding 2000 hours to 8000 hours.
Compliant to the RoHS directive.
AEC-Q200 compliant.
Smaller case size
AEC-Q200 compliant.
Smaller case size
Specifications
Attribute | Value |
|---|---|
| Capacitance | 470µF |
| Voltage | 50V dc |
| Mounting Type | Radial, Through Hole |
| Technology | Aluminium Electrolytic |
| Dimensions | 12.5 (Dia.) x 20mm |
| Length | 20mm |
| Diameter | 12.5mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 5mm |
| Series | UPW |
