Panasonic 330μF Aluminium Electrolytic Capacitor 35V dc, Surface Mount - EEEFN1V331UP
- RS Stock No.:
- 204-3398
- Mfr. Part No.:
- EEEFN1V331UP
- Brand:
- Panasonic
Subtotal (1 reel of 500 units)*
£117.50
(exc. VAT)
£141.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 500 unit(s) shipping from 26 January 2026
- Plus 999,999,000 unit(s) shipping from 06 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 500 + | £0.235 | £117.50 |
*price indicative
- RS Stock No.:
- 204-3398
- Mfr. Part No.:
- EEEFN1V331UP
- Brand:
- Panasonic
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Capacitance | 330µF | |
| Voltage | 35V dc | |
| Mounting Type | Surface Mount | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 8 x 10.2mm | |
| Length | 10.2mm | |
| Minimum Operating Temperature | -55°C | |
| Diameter | 8mm | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 3.1mm | |
| Ripple Current | 600mA | |
| Automotive Standard | AEC-Q200 | |
| Series | FN-V | |
| Equivalent Series Resistance | 160mΩ | |
| Tolerance | ±20% | |
| Polarised | Polar | |
Select all | ||
|---|---|---|
Brand Panasonic | ||
Capacitance 330µF | ||
Voltage 35V dc | ||
Mounting Type Surface Mount | ||
Technology Aluminium Electrolytic | ||
Dimensions 8 x 10.2mm | ||
Length 10.2mm | ||
Minimum Operating Temperature -55°C | ||
Diameter 8mm | ||
Maximum Operating Temperature +105°C | ||
Lead Pitch 3.1mm | ||
Ripple Current 600mA | ||
Automotive Standard AEC-Q200 | ||
Series FN-V | ||
Equivalent Series Resistance 160mΩ | ||
Tolerance ±20% | ||
Polarised Polar | ||
