Nichicon 4.7μF Aluminium Electrolytic Capacitor 400V dc, Surface Mount - UUX2G4R7MNL1GS
- RS Stock No.:
- 187-2460
- Mfr. Part No.:
- UUX2G4R7MNL1GS
- Brand:
- Nichicon
Bulk discount available
Subtotal (1 pack of 25 units)*
£8.975
(exc. VAT)
£10.775
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 999,999,975 unit(s) shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
25 - 75 | £0.359 | £8.98 |
100 - 225 | £0.314 | £7.85 |
250 + | £0.269 | £6.73 |
*price indicative
- RS Stock No.:
- 187-2460
- Mfr. Part No.:
- UUX2G4R7MNL1GS
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Nichicon | |
Capacitance | 4.7µF | |
Voltage | 400V dc | |
Mounting Type | Surface Mount | |
Technology | Aluminium Electrolytic | |
Dimensions | 10.3 (Dia.) x 10.3 x 10mm | |
Height | 10mm | |
Length | 10.3mm | |
Depth | 10.3mm | |
Minimum Operating Temperature | -40°C | |
Diameter | 10.3mm | |
Maximum Operating Temperature | +105°C | |
Lifetime | 3000h | |
Lead Pitch | 4.5mm | |
Leakage Current | 175.2 (Short Term) μA | |
Polarised | Polar | |
Tolerance | ±20% | |
Series | UUX | |
Ripple Current | 40mA | |
Dissipation Factor | 0.25% | |
Select all | ||
---|---|---|
Brand Nichicon | ||
Capacitance 4.7µF | ||
Voltage 400V dc | ||
Mounting Type Surface Mount | ||
Technology Aluminium Electrolytic | ||
Dimensions 10.3 (Dia.) x 10.3 x 10mm | ||
Height 10mm | ||
Length 10.3mm | ||
Depth 10.3mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 10.3mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 3000h | ||
Lead Pitch 4.5mm | ||
Leakage Current 175.2 (Short Term) μA | ||
Polarised Polar | ||
Tolerance ±20% | ||
Series UUX | ||
Ripple Current 40mA | ||
Dissipation Factor 0.25% | ||
- COO (Country of Origin):
- JP
Chip type, operating over wide temperature range of to -55 to +105°C
Designed for surface mounting on high density PC board
Applicable to automatic mounting machine fed with carrier tape
Designed for surface mounting on high density PC board
Applicable to automatic mounting machine fed with carrier tape
