RS PRO 100 μF Capacitor 50V dc, Radial, Through Hole Radial Lead

View all Aluminium Capacitors
Bulk discount available

Subtotal (1 pack of 50 units)*

£7.45

(exc. VAT)

£8.95

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • Plus 500 unit(s) shipping from 27 April 2026
  • Plus 100 unit(s) shipping from 04 May 2026
  • Plus 1,000 unit(s) shipping from 17 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
Per Pack*
50 - 200£0.149£7.45
250 - 450£0.137£6.85
500 +£0.124£6.20

*price indicative

RS Stock No.:
181-5554
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Product Type

Capacitor

Capacitance

100μF

Voltage

50V dc

Construction

Radial Can

Mount Type

Radial, Through Hole

Height

11mm

Length

11mm

Minimum Operating Temperature

-40°C

Diameter

8mm

Pin Count

2

Termination Type

Radial Lead

Capacitor Ripple Current

465mA

Maximum Operating Temperature

105°C

Lifetime

1000 h

Standards/Approvals

RoHS

Lead Pitch

3.5mm

Series

LPS

Tolerance

±20 %

Leakage Current

3μA

Automotive Standard

No

Dissipation Factor

10%

COO (Country of Origin):
TW

RS PRO Electrolytic Capacitor


The RS PRO electrolytic capacitor has a safety vent design with through-hole mounting and features a capacitance of 100μF, at a rated voltage of 50VDC. The RS PRO capacitor has a lifetime of 1000 hours and tolerance is ±20%.

Features and Benefits


• Diameter is 8mm

• Dissipation factor is 10%

• Height is 11mm

• Lead pitch is 3.5mm

• Leakage current is 2μA

• Operating temperature ranging between -40°C and 105°C

• Ripple current is 465mA

• Working voltage is 50VDC

Applications


• Communication equipment

• Industrial measuring instruments

• Switching power supply

Certifications


• ANSI/ESD S20.20:2014

• BS EN 61340-5-1:2007
