RS PRO 100 μF Capacitor 25V dc, Radial, Through Hole Radial Lead

View all Aluminium Capacitors
Bulk discount available

Subtotal (1 pack of 100 units)*

£7.40

(exc. VAT)

£8.90

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • 600 unit(s) shipping from 11 May 2026
  • Plus 2,000 unit(s) shipping from 17 August 2026
  • Plus 2,000 unit(s) shipping from 14 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
Per Pack*
100 - 400£0.074£7.40
500 +£0.056£5.60

*price indicative

RS Stock No.:
181-5448
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Capacitance

100μF

Product Type

Capacitor

Voltage

25V dc

Construction

Radial Can

Mount Type

Radial, Through Hole

Height

11mm

Length

11mm

Minimum Operating Temperature

-40°C

Diameter

6mm

Termination Type

Radial Lead

Capacitor Ripple Current

370mA

Pin Count

2

Maximum Operating Temperature

105°C

Lifetime

1000 h

Standards/Approvals

RoHS

Lead Pitch

2.5mm

Tolerance

±20 %

Leakage Current

3μA

Automotive Standard

No

Series

RS PRO

Dissipation Factor

14%

RS PRO Electrolytic Capacitor


The RS PRO electrolytic capacitor has a safety vent design with through-hole mounting and features a capacitance of 100μF, at a rated voltage of 25VDC. The RS PRO capacitor has a lifetime of 1000 hours and tolerance is ±20%.

Features and Benefits


• Diameter is 6mm

• Dissipation factor is 14%

• Height is 11mm

• Lead pitch is 2.5mm

• Leakage current is 3μA

• Operating temperature ranging between -40°C and 105°C

• Ripple current is 370mA

• Working voltage is 25VDC

Applications


• Computer peripheral

• Mother board

Certifications


• ANSI/ESD S20.20:2014

• BS EN 61340-5-1:2007
