RS PRO 47μF Aluminium Electrolytic Capacitor 35V dc, Radial, Through Hole

View all Aluminium Capacitors
Bulk discount available

Subtotal (1 pack of 100 units)*

£7.00

(exc. VAT)

£8.00

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 200 unit(s) ready to ship
  • Plus 100 unit(s) ready to ship from another location
  • Plus 1,800 unit(s) shipping from 28 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
100 - 200£0.07£7.00
300 - 400£0.06£6.00
500 +£0.046£4.60

*price indicative

RS Stock No.:
181-5444
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Capacitance

47µF

Voltage

35V dc

Mounting Type

Radial, Through Hole

Technology

Aluminium Electrolytic

Dimensions

6 Dia. x 11mm

Height

11mm

Minimum Operating Temperature

-40°C

Diameter

6mm

Maximum Operating Temperature

105°C

Lifetime

1000h

Lead Pitch

2.5mm

Leakage Current

≦0.01 CV or 3 μA @ 1 min

Tolerance

±20%

Ripple Current

250mA

Dissipation Factor

12%

COO (Country of Origin):
TW

RS PRO Electrolytic Capacitor


The RS PRO 47μF through-hole mount electrolytic capacitor has a voltage rating of 35VDC and leakage current of 3μA. This low impedance capacitor has dimensions of 6mm x 11mm (diameter x length). This capacitor is designed with a safety vent construction.

Features and Benefits


• Tolerance: ±20%
• Lifetime: 1000 hours
• Ripple current: 250mA
• Dissipation factor: 12%
• Lead pitch: 2.5mm
• Impedance: 0.53ohm
• Operating temperature ranging between -40°C and 105°C

Applications


• Motherboard
• Computer peripheral

Certifications


• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
