Panasonic 1300μF Aluminium Electrolytic Capacitor 35V dc, Radial, Through Hole - EEUFP1V132
- RS Stock No.:
- 179-3213
- Mfr. Part No.:
- EEUFP1V132
- Brand:
- Panasonic
Available to back order for despatch 01/10/2024
Added
Price Each (In a Pack of 5)
£1.45
(exc. VAT)
£1.74
(inc. VAT)
| Units | Per unit | Per Pack* |
| 5 - 45 | £1.45 | £7.25 |
| 50 - 95 | £1.348 | £6.74 |
| 100 - 245 | £1.25 | £6.25 |
| 250 - 495 | £1.174 | £5.87 |
| 500 + | £1.044 | £5.22 |
| *price indicative | ||
- RS Stock No.:
- 179-3213
- Mfr. Part No.:
- EEUFP1V132
- Brand:
- Panasonic
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- MY
Product Details
Features
High ripple current (2 to 2.5 times as high as FC series)
Large capacitance (Up to 60 % larger than FC series)
Endurance : 105 °C 4000 h to 5000 h
High ripple current (2 to 2.5 times as high as FC series)
Large capacitance (Up to 60 % larger than FC series)
Endurance : 105 °C 4000 h to 5000 h
Specifications
Attribute | Value |
|---|---|
| Capacitance | 1300µF |
| Voltage | 35V dc |
| Mounting Type | Radial, Through Hole |
| Technology | Aluminium Electrolytic |
| Dimensions | 12.5 Dia. x 25mm |
| Height | 25mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 12.5mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 5000h |
| Lead Pitch | 5mm |
| Polarised | Polar |
| Equivalent Series Resistance | 30mΩ |
| Ripple Current | 4000mArms |
| Leakage Current | 455 (Maximum) μA |
| Automotive Standard | AEC-Q200 |
| Series | FP |
| Tolerance | ±20% |
| Dissipation Factor | 0.12% |
