Panasonic 510μF Aluminium Electrolytic Capacitor 35V dc, Radial, Through Hole - EEUFP1V511
- RS Stock No.:
- 179-3207
- Mfr. Part No.:
- EEUFP1V511
- Brand:
- Panasonic
Subtotal (1 pack of 10 units)*
£3.96
(exc. VAT)
£4.75
(inc. VAT)
FREE delivery for orders over £50.00
Last RS stock
- Final 1,140 unit(s), ready to ship
Units | Per unit | Per Pack* |
|---|---|---|
| 10 + | £0.396 | £3.96 |
*price indicative
- RS Stock No.:
- 179-3207
- Mfr. Part No.:
- EEUFP1V511
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Capacitance | 510µF | |
| Voltage | 35V dc | |
| Mounting Type | Radial, Through Hole | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 10 (Dia.) x 16mm | |
| Height | 16mm | |
| Minimum Operating Temperature | -55°C | |
| Diameter | 10mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 4000h | |
| Lead Pitch | 5mm | |
| Series | FP | |
| Tolerance | ±20% | |
| Polarised | Polar | |
| Leakage Current | 178.5 (Maximum) μA | |
| Equivalent Series Resistance | 60mΩ | |
| Automotive Standard | AEC-Q200 | |
| Ripple Current | 2500mArms | |
| Dissipation Factor | 0.12% | |
Select all | ||
|---|---|---|
Brand Panasonic | ||
Capacitance 510µF | ||
Voltage 35V dc | ||
Mounting Type Radial, Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 10 (Dia.) x 16mm | ||
Height 16mm | ||
Minimum Operating Temperature -55°C | ||
Diameter 10mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 4000h | ||
Lead Pitch 5mm | ||
Series FP | ||
Tolerance ±20% | ||
Polarised Polar | ||
Leakage Current 178.5 (Maximum) μA | ||
Equivalent Series Resistance 60mΩ | ||
Automotive Standard AEC-Q200 | ||
Ripple Current 2500mArms | ||
Dissipation Factor 0.12% | ||
- COO (Country of Origin):
- MY
Features
High ripple current (2 to 2.5 times as high as FC series)
Large capacitance (Up to 60 % larger than FC series)
Endurance : 105 °C 4000 h to 5000 h
High ripple current (2 to 2.5 times as high as FC series)
Large capacitance (Up to 60 % larger than FC series)
Endurance : 105 °C 4000 h to 5000 h
