Panasonic 2000μF Aluminium Electrolytic Capacitor 25V dc, Radial, Through Hole - EEUFP1E202
- RS Stock No.:
- 179-3158
- Mfr. Part No.:
- EEUFP1E202
- Brand:
- Panasonic
Bulk discount available
Subtotal (1 bag of 200 units)*
£211.80
(exc. VAT)
£254.20
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 200 - 200 | £1.059 | £211.80 |
| 400 + | £1.029 | £205.80 |
*price indicative
- RS Stock No.:
- 179-3158
- Mfr. Part No.:
- EEUFP1E202
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Capacitance | 2000µF | |
| Voltage | 25V dc | |
| Mounting Type | Radial, Through Hole | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 12.5 Dia. x 25mm | |
| Height | 25mm | |
| Minimum Operating Temperature | -55°C | |
| Diameter | 12.5mm | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 5mm | |
| Lifetime | 5000h | |
| Ripple Current | 4000mArms | |
| Equivalent Series Resistance | 30mΩ | |
| Leakage Current | 500 (Maximum) μA | |
| Polarised | Polar | |
| Tolerance | ±20% | |
| Automotive Standard | AEC-Q200 | |
| Series | FP | |
| Dissipation Factor | 0.14% | |
Select all | ||
|---|---|---|
Brand Panasonic | ||
Capacitance 2000µF | ||
Voltage 25V dc | ||
Mounting Type Radial, Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 12.5 Dia. x 25mm | ||
Height 25mm | ||
Minimum Operating Temperature -55°C | ||
Diameter 12.5mm | ||
Maximum Operating Temperature +105°C | ||
Lead Pitch 5mm | ||
Lifetime 5000h | ||
Ripple Current 4000mArms | ||
Equivalent Series Resistance 30mΩ | ||
Leakage Current 500 (Maximum) μA | ||
Polarised Polar | ||
Tolerance ±20% | ||
Automotive Standard AEC-Q200 | ||
Series FP | ||
Dissipation Factor 0.14% | ||
- COO (Country of Origin):
- MY
Features
High ripple current (2 to 2.5 times as high as FC series)
Large capacitance (Up to 60 % larger than FC series)
Endurance : 105 °C 4000 h to 5000 h
High ripple current (2 to 2.5 times as high as FC series)
Large capacitance (Up to 60 % larger than FC series)
Endurance : 105 °C 4000 h to 5000 h
