Panasonic 470μF Aluminium Electrolytic Capacitor 80V dc, Radial, Through Hole - EEUFS1K471L
- RS Stock No.:
- 176-3922
- Mfr. Part No.:
- EEUFS1K471L
- Brand:
- Panasonic
Bulk discount available
Subtotal (1 pack of 5 units)*
£7.49
(exc. VAT)
£8.99
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 20 unit(s) ready to ship
- Plus 100 unit(s) shipping from 29 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 15 | £1.498 | £7.49 |
| 20 - 45 | £1.022 | £5.11 |
| 50 - 95 | £0.906 | £4.53 |
| 100 + | £0.77 | £3.85 |
*price indicative
- RS Stock No.:
- 176-3922
- Mfr. Part No.:
- EEUFS1K471L
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Capacitance | 470µF | |
| Voltage | 80V dc | |
| Mounting Type | Radial, Through Hole | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 12.5 Dia. x 30mm | |
| Height | 30mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 12.5mm | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 5mm | |
| Lifetime | 10000h | |
| Leakage Current | 0.01 CV (After 2 Minutes) μA | |
| Ripple Current | 2.2A | |
| Series | FS | |
| Polarised | Polar | |
| Tolerance | ±20% | |
| Dissipation Factor | 0.08% | |
Select all | ||
|---|---|---|
Brand Panasonic | ||
Capacitance 470µF | ||
Voltage 80V dc | ||
Mounting Type Radial, Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 12.5 Dia. x 30mm | ||
Height 30mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 12.5mm | ||
Maximum Operating Temperature +105°C | ||
Lead Pitch 5mm | ||
Lifetime 10000h | ||
Leakage Current 0.01 CV (After 2 Minutes) μA | ||
Ripple Current 2.2A | ||
Series FS | ||
Polarised Polar | ||
Tolerance ±20% | ||
Dissipation Factor 0.08% | ||
- COO (Country of Origin):
- MY
Panasonic Electrolytic Capacitor
The Panasonic FS series electrolytic capacitor has 470μF capacitance and is through-hole mount. It has a diameter of 12.5mm, a height of 30mm and a lead pitch of 5mm. This polar capacitor is made from aluminium and the body shape is radial lead type. It requires a voltage of 80VDC and a ripple current of 2.2A.
Features and Benefits
• Endurance of 5000hrs to 10000hrs at 105°C
• Leakage current is 0.01μA
• 10000hrs lifetime
• Low ESR
• Operating temperature ranges between -40°C and 105°C
• Tolerance is ±20%
• Leakage current is 0.01μA
• 10000hrs lifetime
• Low ESR
• Operating temperature ranges between -40°C and 105°C
• Tolerance is ±20%
Applications
• Computer motherboards
• Domestic appliances
• Power supplies
• Domestic appliances
• Power supplies
