- RS Stock No.:
- 171-3206
- Mfr. Part No.:
- B41231C7109M000
- Brand:
- EPCOS
720 In stock - FREE next working day delivery available
Added
Price Each (In a Box of 80)
£1.54
(exc. VAT)
£1.85
(inc. VAT)
Units | Per unit | Per Box* |
80 - 320 | £1.54 | £123.20 |
400 + | £1.497 | £119.76 |
*price indicative |
- RS Stock No.:
- 171-3206
- Mfr. Part No.:
- B41231C7109M000
- Brand:
- EPCOS
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- HU
Product Details
Applications:
Professional power supplies
Features:
High ripple current capability
Useful life of 2000 h at 85 °C
Construction:
Aluminium case, fully insulated with PET or PVC
Snap-in solder pins to hold component in place on PC-board
Minus pole marking on the insulating sleeve
Case with safety vent on the base
Professional power supplies
Features:
High ripple current capability
Useful life of 2000 h at 85 °C
Construction:
Aluminium case, fully insulated with PET or PVC
Snap-in solder pins to hold component in place on PC-board
Minus pole marking on the insulating sleeve
Case with safety vent on the base
Specifications
Attribute | Value |
---|---|
Capacitance | 10000µF |
Voltage | 35V dc |
Mounting Type | Snap-In |
Technology | Aluminium Electrolytic |
Dimensions | 30 (Dia.) x 30mm |
Height | 30mm |
Minimum Operating Temperature | -40°C |
Diameter | 30mm |
Maximum Operating Temperature | +85°C |
Lifetime | 2000h |
Lead Pitch | 10mm |
Ripple Current | 4.58A |
Series | B41231 |
Polarised | Polar |
Tolerance | ±20% |
Dissipation Factor | 0.4% |
