CHEMI-CON 820μF Aluminium Electrolytic Capacitor 200V dc, Snap-In - EKMQ201VSN821MP45S
- RS Stock No.:
- 170-0636
- Mfr. Part No.:
- EKMQ201VSN821MP45S
- Brand:
- CHEMI-CON
Subtotal (1 box of 200 units)*
£540.80
(exc. VAT)
£649.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 200 unit(s) shipping from 28 November 2025
- Plus 999,999,600 unit(s) shipping from 06 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 200 + | £2.704 | £540.80 |
*price indicative
- RS Stock No.:
- 170-0636
- Mfr. Part No.:
- EKMQ201VSN821MP45S
- Brand:
- CHEMI-CON
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | CHEMI-CON | |
| Capacitance | 820µF | |
| Voltage | 200V dc | |
| Mounting Type | Snap-In | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 22 (Dia.) x 45mm | |
| Length | 45mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 22mm | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 10mm | |
| Lifetime | 2000h | |
| Leakage Current | ≤ 3 CV μA | |
| Ripple Current | 2.04Arms | |
| Series | KMQ | |
| Tolerance | ±20% | |
Select all | ||
|---|---|---|
Brand CHEMI-CON | ||
Capacitance 820µF | ||
Voltage 200V dc | ||
Mounting Type Snap-In | ||
Technology Aluminium Electrolytic | ||
Dimensions 22 (Dia.) x 45mm | ||
Length 45mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 22mm | ||
Maximum Operating Temperature +105°C | ||
Lead Pitch 10mm | ||
Lifetime 2000h | ||
Leakage Current ≤ 3 CV μA | ||
Ripple Current 2.04Arms | ||
Series KMQ | ||
Tolerance ±20% | ||
- COO (Country of Origin):
- MY
KMQ Series Snap-In Aluminium Electrolytic Capacitors
KMQ series aluminium electrolytic capacitors with a large capacitance of up to 2200μF and down-sized snap-in terminals. These KMQ aluminium electrolytic capacitors can operate up to 2000 hours @ 105°C and are non solvent resistant.
