Vishay 1000μF Aluminium Electrolytic Capacitor 35V dc, Radial, Through Hole - MAL225090105E3

View all Aluminium Capacitors
Currently unavailable
Sorry, we don't know when this will be back in stock.
RS Stock No.:
159-5960
Mfr. Part No.:
MAL225090105E3
Brand:
Vishay
Find similar products by selecting one or more attributes.
Select all

Brand

Vishay

Capacitance

1000µF

Voltage

35V dc

Mounting Type

Radial, Through Hole

Technology

Aluminium Electrolytic

Dimensions

16.5 Dia. x 22mm

Height

22mm

Minimum Operating Temperature

-55°C

Diameter

16.5mm

Maximum Operating Temperature

+105°C

Lifetime

7000h

Lead Pitch

7.5mm

Polarised

Polar

Tolerance

±20%

Leakage Current

353 μA

Ripple Current

1.84A

Automotive Standard

AEC-Q200

Series

RMI-V

Dissipation Factor

0.12%

COO (Country of Origin):
AT
Aluminium Electrolytic Capacitors Radial Miniature, Low Impedance, High Vibration Capability

Very long useful life: 7000 h to 10 000 h at
105 °C, high stability, high reliability
Very low impedance and low ESR in smaller case sizes than the 136 RVI series
Excellent ripple current capability
High vibration resistance up to 50 g
AEC-Q200 qualified
Polarized aluminum electrolytic capacitors, non-solid electrolyte
Radial leads, cylindrical aluminum case, insulated with a blue sleeve
Charge and discharge proof
Material categorization: for definitions of compliance
APPLICATIONS
Power supplies (SMPS, DC/DC converters) for general industrial, EDP, audio-video, automotive, and Telecommunications
Smoothing, filtering, buffering
