KEMET 30000μF Aluminium Electrolytic Capacitor 250V dc, Screw Terminal - ALS80A303QT250

View all Aluminium Capacitors

Subtotal (1 box of 8 units)*

£788.96

(exc. VAT)

£946.72

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • 88 unit(s) shipping from 20 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Box*
8 +£98.62£788.96

*price indicative

RS Stock No.:
144-3179
Mfr. Part No.:
ALS80A303QT250
Brand:
KEMET
Find similar products by selecting one or more attributes.
Select all

Brand

KEMET

Capacitance

30000µF

Voltage

250V dc

Mounting Type

Screw Terminal

Technology

Aluminium Electrolytic

Dimensions

90 (Dia.) x 220mm

Height

220mm

Minimum Operating Temperature

-40°C

Diameter

90mm

Maximum Operating Temperature

+105°C

Lifetime

15000h

Lead Pitch

31.8mm

Leakage Current

6000 μA

Equivalent Series Resistance

11mΩ

Polarised

Polar

Tolerance

±20%

Ripple Current

32.5A

Series

ALS80

COO (Country of Origin):
PT
KEMET's ALS80/81 high CV screw terminal capacitors feature the same high ripple currents and long life characteristics as the ALS70/71 series, but can operate at higher temperatures. Volumetric efficiency ensures the maximum capacitance capability in a smaller size. They are similarly suited for high reliability and long life applications such as frequency converters, uninterruptible power supply (UPS) systems, and switch mode power supplies (SMPS). The extended temperature range allows increased ripple currents at lower temperatures.
