Wurth Elektronik 390μF Aluminium Electrolytic Capacitor 450V dc, Snap-In - 861141486023
- RS Stock No.:
- 124-7749
- Mfr. Part No.:
- 861141486023
- Brand:
- Wurth Elektronik
Subtotal (1 tray of 50 units)*
£587.25
(exc. VAT)
£704.70
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 13 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tray* |
|---|---|---|
| 50 + | £11.745 | £587.25 |
*price indicative
- RS Stock No.:
- 124-7749
- Mfr. Part No.:
- 861141486023
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Capacitance | 390µF | |
| Voltage | 450V dc | |
| Mounting Type | Snap-In | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 35 (Dia.) x 42mm | |
| Depth | 42mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 35mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 3000h | |
| Lead Pitch | 10mm | |
| Leakage Current | 1256.78 μA | |
| Series | WCAP-AI3H | |
| Tolerance | ±20% | |
| Ripple Current | 1.5A | |
| Polarised | Polar | |
| Dissipation Factor | 20% | |
Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Capacitance 390µF | ||
Voltage 450V dc | ||
Mounting Type Snap-In | ||
Technology Aluminium Electrolytic | ||
Dimensions 35 (Dia.) x 42mm | ||
Depth 42mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 35mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 3000h | ||
Lead Pitch 10mm | ||
Leakage Current 1256.78 μA | ||
Series WCAP-AI3H | ||
Tolerance ±20% | ||
Ripple Current 1.5A | ||
Polarised Polar | ||
Dissipation Factor 20% | ||
- COO (Country of Origin):
- CN
Wurth Elektronik WCAP-AI3H Series Aluminium Electrolytic Capacitors
Wurth Elektronik WCAP- AI3H Series aluminium electrolytic capacitors feature an operating temperature of up to +105°C. This general purpose capacitor family WCAP- AI3H Series offer a capacitance value from 68uF to 150uF.
