MEAN WELL 28.5W Power Brick AC/DC Adapter -5V dc Output, (-5 V dc) 0.1 → 0.3A Output
- RS Stock No.:
- 123-5021
- Mfr. Part No.:
- GP25B13A-R1B
- Brand:
- MEAN WELL
Subtotal (1 unit)*
£31.78
(exc. VAT)
£38.14
(inc. VAT)
FREE delivery for orders over £50.00
- 1 unit(s) shipping from 06 March 2026
Units | Per unit |
|---|---|
| 1 + | £31.78 |
*price indicative
- RS Stock No.:
- 123-5021
- Mfr. Part No.:
- GP25B13A-R1B
- Brand:
- MEAN WELL
Select all | Attribute | Value |
|---|---|---|
| Brand | MEAN WELL | |
| Adapter Type | Power Brick Adapter | |
| Output Voltage | -5 V dc, 5 V dc, 12V dc | |
| Input Voltage | 80 → 264V ac | |
| Output Current | (-5 V dc) 0.1 → 0.3 A, (12 V dc) 0.2 → 1.2 A, (5 V dc) 0.5 → 2.5A | |
| Maximum Temperature | +70°C | |
| Output Connector | 4-Pin Power DIN | |
| Input Connector | IEC 320-C14 | |
| Number of Outputs | 3 | |
| Power Rating | 28.5W | |
| Cable Length | 1530mm | |
| Efficiency | 80% | |
| Standards Met | CB, CE, CSA 22.2, cULus Recognised, EISA 2007/DOE, EN 55022 Class B, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, FCC PART 15/CISP22 Class B, MIL-HDBK-217F, TUV Rheinland, UL 60950-1 | |
| MTBF | 620kh | |
| Energy Efficiency Level | VI | |
| Depth | 36mm | |
| Minimum Temperature | -20°C | |
| Line Regulation Range | ±1% | |
| Series | GP25B-T | |
| Length | 107.5mm | |
| Width | 67mm | |
| Load Regulation | ±3 % @ -5 V dc, ±5 % @ 12 V dc, ±5 % @ 5V dc | |
Select all | ||
|---|---|---|
Brand MEAN WELL | ||
Adapter Type Power Brick Adapter | ||
Output Voltage -5 V dc, 5 V dc, 12V dc | ||
Input Voltage 80 → 264V ac | ||
Output Current (-5 V dc) 0.1 → 0.3 A, (12 V dc) 0.2 → 1.2 A, (5 V dc) 0.5 → 2.5A | ||
Maximum Temperature +70°C | ||
Output Connector 4-Pin Power DIN | ||
Input Connector IEC 320-C14 | ||
Number of Outputs 3 | ||
Power Rating 28.5W | ||
Cable Length 1530mm | ||
Efficiency 80% | ||
Standards Met CB, CE, CSA 22.2, cULus Recognised, EISA 2007/DOE, EN 55022 Class B, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, FCC PART 15/CISP22 Class B, MIL-HDBK-217F, TUV Rheinland, UL 60950-1 | ||
MTBF 620kh | ||
Energy Efficiency Level VI | ||
Depth 36mm | ||
Minimum Temperature -20°C | ||
Line Regulation Range ±1% | ||
Series GP25B-T | ||
Length 107.5mm | ||
Width 67mm | ||
Load Regulation ±3 % @ -5 V dc, ±5 % @ 12 V dc, ±5 % @ 5V dc | ||
- COO (Country of Origin):
- TW
Mean Well GP25/50 Series Desk Top Power supply
Universal AC input / full range.
Industry standard protections such as short circuit, overload, over voltage & over temperature.
Level VI energy efficiency rating.
Fully enclosed plastic case.
LED power indication
