onsemi, 16V Zener Diode 2% 250 mW SMT 2-Pin SOD-923
- RS Stock No.:
- 805-4563
- Mfr. Part No.:
- NZ9F16VST5G
- Brand:
- ON Semiconductor
Discontinued
- RS Stock No.:
- 805-4563
- Mfr. Part No.:
- NZ9F16VST5G
- Brand:
- ON Semiconductor
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ON Semiconductor | |
| Nominal Zener Voltage | 16V | |
| Diode Configuration | Single | |
| Mounting Type | Surface Mount | |
| Number of Elements per Chip | 1 | |
| Maximum Power Dissipation | 250 mW | |
| Package Type | SOD-923 | |
| Zener Type | Voltage Regulator | |
| Zener Voltage Tolerance | 2% | |
| Pin Count | 2 | |
| Test Current | 5mA | |
| Maximum Zener Impedance | 50Ω | |
| Maximum Reverse Leakage Current | 100nA | |
| Dimensions | 0.85 x 0.65 x 0.4mm | |
| Minimum Operating Temperature | -65 °C | |
| Maximum Operating Temperature | +150 °C | |
| Select all | ||
|---|---|---|
Brand ON Semiconductor | ||
Nominal Zener Voltage 16V | ||
Diode Configuration Single | ||
Mounting Type Surface Mount | ||
Number of Elements per Chip 1 | ||
Maximum Power Dissipation 250 mW | ||
Package Type SOD-923 | ||
Zener Type Voltage Regulator | ||
Zener Voltage Tolerance 2% | ||
Pin Count 2 | ||
Test Current 5mA | ||
Maximum Zener Impedance 50Ω | ||
Maximum Reverse Leakage Current 100nA | ||
Dimensions 0.85 x 0.65 x 0.4mm | ||
Minimum Operating Temperature -65 °C | ||
Maximum Operating Temperature +150 °C | ||
Zener Diodes 200mW, NZ9FxxxST Series, ON Semiconductor
Surface Mount case: SOD-923
Zener Diodes, ON Semiconductor
