Vishay, 12V Demultiplexer SMT SOD-323
- RS Stock No.:
- 180-8801
- Mfr. Part No.:
- BZX384C12-E3-08
- Brand:
- Vishay
Bulk discount available
Subtotal (1 pack of 100 units)*
£3.10
(exc. VAT)
£3.70
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 14,900 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
100 - 900 | £0.031 | £3.10 |
1000 - 2400 | £0.028 | £2.80 |
2500 - 4900 | £0.027 | £2.70 |
5000 - 9900 | £0.021 | £2.10 |
10000 + | £0.018 | £1.80 |
*price indicative
- RS Stock No.:
- 180-8801
- Mfr. Part No.:
- BZX384C12-E3-08
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Vishay | |
Diode Configuration | Single | |
Nominal Zener Voltage | 12V | |
Mounting Type | Surface Mount | |
Package Type | SOD-323 | |
Select all | ||
---|---|---|
Brand Vishay | ||
Diode Configuration Single | ||
Nominal Zener Voltage 12V | ||
Mounting Type Surface Mount | ||
Package Type SOD-323 | ||
- COO (Country of Origin):
- CN
Vishay Zener Diode
The Vishay SOD-323 small-signal Zener diode has a voltage rating of 12VDC and power rating of 200mW at 5% voltage tolerance. The Zener current of the diode is 0.1μA and reverse current rating is 0.1μA.
Features and Benefits
• ESD capability according to AEC-Q101: human body model > 8kV and machine model > 800V
• Lead (Pb) free component
• Operating junction temperature ranges between -55°C and 150°C
• Replace C with B for ±2% tolerance
• Silicon planar Zener diode
• The Zener voltages are graded according to the international standard
• Lead (Pb) free component
• Operating junction temperature ranges between -55°C and 150°C
• Replace C with B for ±2% tolerance
• Silicon planar Zener diode
• The Zener voltages are graded according to the international standard
Applications
• Voltage regulators
• Voltage stabilization
• Voltage stabilization
Certifications
• AEC-Q101 qualified
• Automotive Grade
• e3
• J-STD-020
• UL94 listed
• Automotive Grade
• e3
• J-STD-020
• UL94 listed
