Nexperia, 15V Zener Diode ±5% 1.3 W Through Hole 2-Pin DO-41
- RS Stock No.:
- 179-1140
- Mfr. Part No.:
- BZV85-C15,113
- Brand:
- Nexperia
Available to back order for despatch 09/09/2024
Added
Price Each (On a Reel of 5000)
£0.067
(exc. VAT)
£0.08
(inc. VAT)
| Units | Per unit | Per Reel* |
| 5000 + | £0.067 | £335.00 |
| *price indicative | ||
- RS Stock No.:
- 179-1140
- Mfr. Part No.:
- BZV85-C15,113
- Brand:
- Nexperia
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Zener Diodes 1.3W, BZV85 Series, Nexperia
Zener Diodes, Nexperia
Specifications
Attribute | Value |
|---|---|
| Nominal Zener Voltage | 15V |
| Diode Configuration | Single |
| Mounting Type | Through Hole |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation | 1.3 W |
| Package Type | DO-41 |
| Zener Type | Voltage Regulator |
| Zener Voltage Tolerance | ±5% |
| Pin Count | 2 |
| Test Current | 15mA |
| Maximum Zener Impedance | 15Ω |
| Maximum Reverse Leakage Current | 50nA |
| Dimensions | 4.8 x 2.6 x 2.6mm |
| Minimum Operating Temperature | -65 °C |
| Maximum Operating Temperature | +200 °C |
| Typical Voltage Temperature Coefficient | 11.25mV/°C |
