Molex, 172708 Male PCB Connector Housing, 4.2mm Pitch, 12 Way, 2 Row

This PCB connector housing belongs to the Mini-Fit family of power connectors, specifically designed as a receptacle connector. It features a straight body orientation and accommodates up to 12 circuits in a dual-row arrangement, with a pitch of 4.2mm. Made from durable nylon, this electrical connector housing is not only glow-wire capable but also suitable for applications operating between -40°C and +105°C.

• Made from robust nylon for enhanced durability
• Supports up to 12 circuits for versatile connections
• Glow-wire capable for increased safety in applications
• Designed with a straight body for ease of installation
• Dual-row layout optimises space while connecting multiple wires
• Locking mechanism ensures stable mating with connectors

• Ideal for power connections in automation systems
• Used for wire-to-board configurations in electronic devices
• Suitable for constructing reliable connections in mechanical assemblies
• Utilised in various electrical requiring dual-row connections

The nylon material provides excellent resistance to high temperatures and harsh chemicals, ensuring reliable performance in demanding conditions. Its strength also reduces the risk of breakage during installation and use.

The glow-wire capability helps prevent ignition when exposed to elevated temperatures, making it suitable for applications where safety is a critical concern. This feature ensures that the connector maintains integrity and performance even under heat stress.

This housing is compatible with components like Mini-Fit Jr. plug housings and Mini-Fit TPA2 plug housings, allowing for flexible and efficient connections in various configurations.

While designed for electronic connections, additional protective measures may be required for outdoor use to shield against environmental factors like moisture and extreme temperatures.
