JST, VH Connector Housing, 3.96mm Pitch, 3 Way, 1 Row
- RS Stock No.:
- 184-8453
- Mfr. Part No.:
- VHR-3M
- Brand:
- JST
Bulk discount available
Subtotal (1 pack of 100 units)*
£8.90
(exc. VAT)
£10.70
(inc. VAT)
FREE delivery for orders over £50.00
Limited stock
- Plus 5,000 left, shipping from 06 October 2025
- Plus 600 left, shipping from 06 October 2025
- Plus 3,400 left, shipping from 18 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 100 - 100 | £0.089 | £8.90 |
| 200 - 300 | £0.084 | £8.40 |
| 400 - 500 | £0.08 | £8.00 |
| 600 - 700 | £0.076 | £7.60 |
| 800 + | £0.072 | £7.20 |
*price indicative
- RS Stock No.:
- 184-8453
- Mfr. Part No.:
- VHR-3M
- Brand:
- JST
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | JST | |
| Number of Contacts | 3 | |
| Number of Rows | 1 | |
| Pitch | 3.96mm | |
| Series | VH | |
| For Use With | VH Disconnectable Crimp Style Connectors | |
| Length | 11.82mm | |
| Width | 10.6mm | |
| Housing Material | PBT | |
Select all | ||
|---|---|---|
Brand JST | ||
Number of Contacts 3 | ||
Number of Rows 1 | ||
Pitch 3.96mm | ||
Series VH | ||
For Use With VH Disconnectable Crimp Style Connectors | ||
Length 11.82mm | ||
Width 10.6mm | ||
Housing Material PBT | ||
- COO (Country of Origin):
- JP
With a large current carrying capacity, the VH connector can be used with a wide variety of signal, power supply, and output circuits. Compact connector (with a mounting height of 16.5mm) with a large capacity (10A). The housing has a lock mechanism which prevents the connector from coming loose due to vibration. The mechanism also prevents misinsertion. This small, field-proven connector for PC boards is reliable and has a large current carrying capacity. It can be used with a wide variety of signal, power supply, and output circuits that appear in consumer electronic products.
Proven box contact
This connector was developed with the same box-shaped contact design used successfully in the NH connectors. The reliable VH connector can be used in a wide variety of applications, from low-voltage, low-current signal circuits to power supply circuits having a relatively large capacity.
Compact connector with a large capacity
Even though this connector has a large current carrying capacity (10A), it is compact, with a mounting height of 16.5mm (.650").
Secure contact and mounting
The housing has a lock mechanism which prevents the connector from coming loose due to vibration. The mechanism also prevents misinsertion (misalignment or reverse insertion).
This connector was developed with the same box-shaped contact design used successfully in the NH connectors. The reliable VH connector can be used in a wide variety of applications, from low-voltage, low-current signal circuits to power supply circuits having a relatively large capacity.
Compact connector with a large capacity
Even though this connector has a large current carrying capacity (10A), it is compact, with a mounting height of 16.5mm (.650").
Secure contact and mounting
The housing has a lock mechanism which prevents the connector from coming loose due to vibration. The mechanism also prevents misinsertion (misalignment or reverse insertion).
