Analog Devices, 1-Channel Low Dropout Voltage, Regulator, 500 mA, 5 V, MSOP 8-Pin
- RS Stock No.:
- 209-6073
- Mfr. Part No.:
- ADP125ACPZ-R7
- Brand:
- Analog Devices
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 209-6073
- Mfr. Part No.:
- ADP125ACPZ-R7
- Brand:
- Analog Devices
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Analog Devices | |
| Regulator Type | Low Dropout Voltage | |
| Product Type | Regulator | |
| Number of Outputs | 1 | |
| Output Voltage | 5 V | |
| Line Regulation | 0.05 %/V | |
| Polarity | Positive | |
| Mount Type | Surface | |
| Quiescent Current | 45μA | |
| Package Type | MSOP | |
| Pin Count | 8 | |
| Output Current | 500mA | |
| Output Type | Adjustable | |
| Switching Regulator | No | |
| Series | ADP125 | |
| Standards/Approvals | RoHS | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 125°C | |
| Minimum Input Voltage | 2.3V | |
| Maximum Input Voltage | 5.5V | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Analog Devices | ||
Regulator Type Low Dropout Voltage | ||
Product Type Regulator | ||
Number of Outputs 1 | ||
Output Voltage 5 V | ||
Line Regulation 0.05 %/V | ||
Polarity Positive | ||
Mount Type Surface | ||
Quiescent Current 45μA | ||
Package Type MSOP | ||
Pin Count 8 | ||
Output Current 500mA | ||
Output Type Adjustable | ||
Switching Regulator No | ||
Series ADP125 | ||
Standards/Approvals RoHS | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 125°C | ||
Minimum Input Voltage 2.3V | ||
Maximum Input Voltage 5.5V | ||
Automotive Standard No | ||
The Analog Devices linear regulators designed to operate from an input voltage between 2.3 V and 5.5 V and to provide up to 500 mA of output current.
Fixed and adjustable output voltage versions
60dB at 100kHz PSRR performance
Logic controlled enable
Excellent load or line transient response
