STMicroelectronics LDLN025PU12R, 1 Linear Voltage, Voltage Regulator 250mA, 1.2 V 4-Pin, DFN
- RS Stock No.:
- 192-4631
- Mfr. Part No.:
- LDLN025PU12R
- Brand:
- STMicroelectronics
Subtotal (1 reel of 5000 units)*
£800.00
(exc. VAT)
£950.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
---|---|---|
5000 + | £0.16 | £800.00 |
*price indicative
- RS Stock No.:
- 192-4631
- Mfr. Part No.:
- LDLN025PU12R
- Brand:
- STMicroelectronics
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | STMicroelectronics | |
Maximum Output Current | 250mA | |
Regulator Type | Linear Voltage | |
Number of Outputs | 1 | |
Output Voltage | 1.2 V | |
Line Regulation | 0.06 %/V | |
Load Regulation | 0.007 %/mA | |
Accuracy | ±4% | |
Mounting Type | Surface Mount | |
Package Type | DFN | |
Quiescent Current | 425µA | |
Pin Count | 4 | |
Output Type | Fixed | |
Dimensions | 1.05 x 1.05 x 0.35mm | |
Minimum Input Voltage | 1.5 V | |
Minimum Operating Temperature | -40 °C | |
Maximum Operating Temperature | +125 °C | |
Maximum Input Voltage | 5.5 V | |
Height | 0.35mm | |
Length | 1.05mm | |
Width | 1.05mm | |
Select all | ||
---|---|---|
Brand STMicroelectronics | ||
Maximum Output Current 250mA | ||
Regulator Type Linear Voltage | ||
Number of Outputs 1 | ||
Output Voltage 1.2 V | ||
Line Regulation 0.06 %/V | ||
Load Regulation 0.007 %/mA | ||
Accuracy ±4% | ||
Mounting Type Surface Mount | ||
Package Type DFN | ||
Quiescent Current 425µA | ||
Pin Count 4 | ||
Output Type Fixed | ||
Dimensions 1.05 x 1.05 x 0.35mm | ||
Minimum Input Voltage 1.5 V | ||
Minimum Operating Temperature -40 °C | ||
Maximum Operating Temperature +125 °C | ||
Maximum Input Voltage 5.5 V | ||
Height 0.35mm | ||
Length 1.05mm | ||
Width 1.05mm | ||
