STMicroelectronics L78M05CV, 1 Linear Voltage, Voltage Regulator 500mA, 5 V 3-Pin, TO-220
- RS Stock No.:
- 168-6064
- Mfr. Part No.:
- L78M05CV
- Brand:
- STMicroelectronics
200 In stock - FREE next working day delivery available
Added
Price Each (In a Tube of 50)
£0.508
(exc. VAT)
£0.61
(inc. VAT)
| Units | Per unit | Per Tube* |
| 50 - 50 | £0.508 | £25.40 |
| 100 - 950 | £0.305 | £15.25 |
| 1000 - 1950 | £0.225 | £11.25 |
| 2000 - 9950 | £0.196 | £9.80 |
| 10000 + | £0.189 | £9.45 |
| *price indicative | ||
- RS Stock No.:
- 168-6064
- Mfr. Part No.:
- L78M05CV
- Brand:
- STMicroelectronics
Technical Reference
Legislation and Compliance
Product Details
L78M Series Linear Voltage Regulator, STMicroelectronics
The L78M series positive linear voltage regulators by STMicroelectronics all have fixed voltage outputs from 5V up to 24 V with a 500mA current output. They are three terminal regulator ICs that are available in a range of packages from TO220, DPAK and IPAK. These devices are suitable for use in many applications including local on-card regulation and power distribution systems. The internal current limiting, thermal shutdown and safe operating area protection make them durable. There are no external components required unless you want to adjust the voltage and current outputs.
Linear Voltage Regulators, STMicroelectronics
Specifications
Attribute | Value |
|---|---|
| Regulator Type | Linear Voltage |
| Maximum Output Current | 500mA |
| Number of Outputs | 1 |
| Output Voltage | 5 V |
| Line Regulation | 100 mV |
| Load Regulation | 100 mV |
| Polarity | Positive |
| Mounting Type | Through Hole |
| Quiescent Current | 6mA |
| Package Type | TO-220 |
| Pin Count | 3 |
| Output Type | Fixed |
| Dimensions | 10.4 x 4.6 x 9.15mm |
| Maximum Input Voltage | 35 V |
| Maximum Operating Temperature | +150 °C |
| Minimum Operating Temperature | 0 °C |
| Height | 9.15mm |
| Width | 4.6mm |
| Length | 10.4mm |
