onsemi MC7806CTG, 1 Linear Voltage, Voltage Regulator 2.2A, 6 V 3-Pin, TO-220

View all Voltage Regulators
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
RS Stock No.:
125-0050
Mfr. Part No.:
MC7806CTG
Brand:
onsemi
Find similar products by selecting one or more attributes.
Select all

Brand

onsemi

Maximum Output Current

2.2A

Regulator Type

Linear Voltage

Output Voltage

6 V

Number of Outputs

1

Line Regulation

24 mV

Accuracy

±4%

Load Regulation

30 mV

Polarity

Positive

Mounting Type

Through Hole

Quiescent Current

3.3mA

Package Type

TO-220

Pin Count

3

Output Type

Fixed

Dimensions

10.28 x 4.82 x 30.02mm

Minimum Operating Temperature

0 °C

Maximum Operating Temperature

+125 °C

Height

30.02mm

Maximum Input Voltage

35 V

Width

4.82mm

Length

10.28mm

COO (Country of Origin):
CZ

7806 Linear Voltage Regulator, ON Semiconductor


This remarkable ON Semiconductor linear voltage regulator comes under the MC7806 family. These products are monolithic integrated circuits designed as fixed-voltage regulators for a wide range of applications including local, on-card regulation. The positive 7806 voltage regulator requires no external components and incorporates internal thermal overload protection and current limiting plus safe area compensation.

Features and Benefits
• Internal thermal overload protection
• Internal short circuit current limiting
• Output transistor safe – area compensation
• These are Pb-Free devices
• Output current in access of 2.2A
• Output Voltage 6V
• Package type: TO-220
• Accuracy +4%
• 1-Channel 3-Pin

Applications
Linear regulators are simple voltage regulator circuits commonly adopted in electronics. A Linear voltage regulator uses a closed feedback loop to bias a pass element to maintain a steady voltage across output terminals. Linear regulators are most commonly highly integrated, which include the pass element and feedback loop.
