Bourns, CV Disc Varistor 900 pF 4500 A, Clamping 395 V, Varistor 240 V, Disc (14 mm)
- RS Stock No.:
- 245-9076
- Mfr. Part No.:
- CV150K14BL1
- Brand:
- Bourns
Bulk discount available
Subtotal (1 pack of 10 units)*
£4.42
(exc. VAT)
£5.30
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 9,970 unit(s) shipping from 16 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 10 - 90 | £0.442 | £4.42 |
| 100 - 190 | £0.406 | £4.06 |
| 200 + | £0.307 | £3.07 |
*price indicative
- RS Stock No.:
- 245-9076
- Mfr. Part No.:
- CV150K14BL1
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Varistor Voltage | 240 V | |
| Product Type | Disc Varistor | |
| Clamping Voltage VC | 395V | |
| Packaging | Tape & Reel | |
| Clamping Current | 4500A | |
| Mount Type | Through Hole | |
| Series | CV | |
| Diameter | 16.5 mm | |
| Maximum AC Voltage | 150V ac | |
| Maximum DC Voltage | 200V | |
| Maximum Surge Current | 4500A | |
| Capacitance | 900pF | |
| Minimum Operating Temperature | -40°C | |
| Pin Count | 2 | |
| Length | 20mm | |
| Maximum Operating Temperature | 85°C | |
| Termination Style | Radial | |
| Thickness | 4.8mm | |
| Standards/Approvals | UL, RoHS | |
| Package/Case | Disc (14 mm) | |
| Energy Rating | 81J | |
| Automotive Standard | AEC-Q200 | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Varistor Voltage 240 V | ||
Product Type Disc Varistor | ||
Clamping Voltage VC 395V | ||
Packaging Tape & Reel | ||
Clamping Current 4500A | ||
Mount Type Through Hole | ||
Series CV | ||
Diameter 16.5 mm | ||
Maximum AC Voltage 150V ac | ||
Maximum DC Voltage 200V | ||
Maximum Surge Current 4500A | ||
Capacitance 900pF | ||
Minimum Operating Temperature -40°C | ||
Pin Count 2 | ||
Length 20mm | ||
Maximum Operating Temperature 85°C | ||
Termination Style Radial | ||
Thickness 4.8mm | ||
Standards/Approvals UL, RoHS | ||
Package/Case Disc (14 mm) | ||
Energy Rating 81J | ||
Automotive Standard AEC-Q200 | ||
- COO (Country of Origin):
- SI
The Bourns CV series of transient surge suppressors are disc shaped varistor designed to be operated continuously in low and medium voltage electronic system circuits as well as across AC power lines. Due to their radial lead construction, these component require very little mounting space.
Operating ambient temperature range from -40°C to 85°C
Surge protection
Fast response time
