Bourns, PV Varistor 440pF 10A, Clamping 250V, Varistor 150V, 4032
- RS Stock No.:
- 204-8707
- Mfr. Part No.:
- PV95K4032R2
- Brand:
- Bourns
Available to back order for despatch 18/02/2025
Added
Price Each (On a Reel of 1000)
£0.24
(exc. VAT)
£0.29
(inc. VAT)
| Units | Per unit | Per Reel* |
| 1000 + | £0.24 | £240.00 |
| *price indicative | ||
- RS Stock No.:
- 204-8707
- Mfr. Part No.:
- PV95K4032R2
- Brand:
- Bourns
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- SI
Product Details
The PV series plastic-encapsulated varistor is designed to protect electronic equipment against voltage surges in the low and medium voltage region. It is designed for surface mounting and offers direct SMD equivalents to leaded disc varistors of 5 and 7 mm sizes. The thermoplastic encapsulation is non-flammable and UL 94 V-0 rated. Contacts are made of tinned copper sheet. These transient voltage suppressors cover an operating voltage Vrms from 11 V to 300 V, featuring maximum surge currents from 100 A to 1200 A.
Package size of 4032
Operating voltage range (Vdc) 14 V to 385 V
Operating voltage (Vrms) 11 V to 300 V
Continuous operating temperature 85 °C
Easily solderable tinned copper sheet
Available in tape and reel packaging for automatic pick-and-place
UL 94 V-0 Non-flammable thermoplastic encapsulation
Operating voltage range (Vdc) 14 V to 385 V
Operating voltage (Vrms) 11 V to 300 V
Continuous operating temperature 85 °C
Easily solderable tinned copper sheet
Available in tape and reel packaging for automatic pick-and-place
UL 94 V-0 Non-flammable thermoplastic encapsulation
Specifications
Attribute | Value |
|---|---|
| Varistor Voltage | 150V |
| Maximum AC Voltage Rating | 95V |
| Maximum DC Voltage Rating | 125V |
| Clamping Voltage | 250V |
| Clamping Current | 10A |
| Material | Plastic |
| Energy | 11J |
| Series | PV |
| Maximum Surge Current | 1200A |
| Capacitance | 440pF |
| Length | 10mm |
| Thickness | 4.7mm |
| Package/Case | 4032 |
