Littelfuse, LA Varistor Metal Oxide Varistor 270 pF 50 A, Clamping 2700 V, Varistor 825 V
- RS Stock No.:
- 170-9920
- Mfr. Part No.:
- V480LA40AP
- Brand:
- Littelfuse
Bulk discount available
Subtotal (1 bag of 600 units)*
£206.40
(exc. VAT)
£247.80
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 31 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 600 - 5400 | £0.344 | £206.40 |
| 6000 - 11400 | £0.277 | £166.20 |
| 12000 - 14400 | £0.263 | £157.80 |
| 15000 - 29400 | £0.25 | £150.00 |
| 30000 + | £0.238 | £142.80 |
*price indicative
- RS Stock No.:
- 170-9920
- Mfr. Part No.:
- V480LA40AP
- Brand:
- Littelfuse
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Littelfuse | |
| Product Type | Metal Oxide Varistor | |
| Varistor Voltage | 825 V | |
| Packaging | Bulk or Tape and Reel | |
| Clamping Voltage VC | 2700V | |
| Clamping Current | 50A | |
| Mount Type | Radial | |
| Series | LA Varistor | |
| Maximum AC Voltage | 480V ac | |
| Diameter | 17mm | |
| Maximum Surge Current | 4500A | |
| Maximum DC Voltage | 640V dc | |
| Capacitance | 270pF | |
| Pin Count | 2 | |
| Length | 32mm | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | UL1449, IEC 61051-1, IEC 60950-1 Annex Q for 14mm and 20mm only, IEC 61051-2, CECC 42201-006 | |
| Thickness | 7.3mm | |
| Depth | 10.8mm | |
| Termination Style | Radial | |
| Energy Rating | 360J | |
| Automotive Standard | No | |
| Lead Pitch | 8.5mm | |
| Select all | ||
|---|---|---|
Brand Littelfuse | ||
Product Type Metal Oxide Varistor | ||
Varistor Voltage 825 V | ||
Packaging Bulk or Tape and Reel | ||
Clamping Voltage VC 2700V | ||
Clamping Current 50A | ||
Mount Type Radial | ||
Series LA Varistor | ||
Maximum AC Voltage 480V ac | ||
Diameter 17mm | ||
Maximum Surge Current 4500A | ||
Maximum DC Voltage 640V dc | ||
Capacitance 270pF | ||
Pin Count 2 | ||
Length 32mm | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals UL1449, IEC 61051-1, IEC 60950-1 Annex Q for 14mm and 20mm only, IEC 61051-2, CECC 42201-006 | ||
Thickness 7.3mm | ||
Depth 10.8mm | ||
Termination Style Radial | ||
Energy Rating 360J | ||
Automotive Standard No | ||
Lead Pitch 8.5mm | ||
Littelfuse Metal Oxide Varistors - LA / MA / ZA Series
Littelfuse metal oxide varistors are Compact and versatile, and can be used within a wide range of applications.
The LA series of MOV’s are radial-lead varistors that are designed to be operated continuously across AC power lines.
The MA series of MOV’s are axial-lead varistors that are designed for use in a wide variety of board level industrial and commercial electronic equipment, protecting components and signal/data lines from low energy transients.
The ZA series of MOV’s are radial-lead varistors that are designed for use in the protection of low and medium-voltage circuits and systems. Typical applications include motor control, telecom, automotive systems, solenoid, and power supply circuits to protect circuit board components and maintain data integrity.
