EPCOS, Standard Metal Oxide Varistor 2.1nF 5A, Clamping 135V, Varistor 68V
- RS Stock No.:
- 138-6041
- Mfr. Part No.:
- B72210S0400K101
- Brand:
- EPCOS
820 In stock - FREE next working day delivery available
Price Each (In a Box of 500)
£0.153
(exc. VAT)
£0.184
(inc. VAT)
Units | Per unit | Per Box* |
|---|---|---|
| 500 + | £0.153 | £76.50 |
*price indicative
- RS Stock No.:
- 138-6041
- Mfr. Part No.:
- B72210S0400K101
- Brand:
- EPCOS
Technical Reference
Legislation and Compliance
Product Details
Leaded varistors are varistor elements with lead wires as terminals. The coating of the varistors is made of flame-retardant material.
Wide operating voltage range 11 … 1100 VRMS
High surge current ratings up to 8 kA
No derating up to 105 °C ambient temperature
For S14/ S20 types duty cycle @ 6 kV/ 3 kA = >10 pulses, according to IEC 60950-1,
Annex Q, IEC 61051-2
PSpice models
High surge current ratings up to 8 kA
No derating up to 105 °C ambient temperature
For S14/ S20 types duty cycle @ 6 kV/ 3 kA = >10 pulses, according to IEC 60950-1,
Annex Q, IEC 61051-2
PSpice models
Specifications
Attribute | Value |
|---|---|
| Varistor Voltage | 68V |
| Maximum AC Voltage Rating | 40V |
| Maximum DC Voltage Rating | 56V |
| Clamping Voltage | 135V |
| Clamping Current | 5A |
| Material | Metal |
| Energy | 6.4J |
| Series | Standard |
| Maximum Surge Current | 500A |
| Capacitance | 2.1nF |
| Length | 12mm |
| Depth | 14.5mm |
| Thickness | 4.8mm |
| Dimensions | 12 x 4.8 x 14.5mm |
| Lead Pitch | 2.1 mm, 7.5mm |
