Lapp Data Cable, 0.75 mm², 100 m, Grey Sheath Polyvinyl Chloride
- RS Stock No.:
- 288-6652
- Distrelec Article No.:
- 300-49-429
- Mfr. Part No.:
- 34710
- Brand:
- Lapp
Subtotal (1 reel of 100 metres)*
£631.07
(exc. VAT)
£757.28
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 10 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £631.07 | £6.311 |
*price indicative
- RS Stock No.:
- 288-6652
- Distrelec Article No.:
- 300-49-429
- Mfr. Part No.:
- 34710
- Brand:
- Lapp
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lapp | |
| Product Type | Data Cable | |
| Cross Sectional Area | 0.75 mm² | |
| Cable Length | 100m | |
| Jacket Colour | Grey | |
| Jacket Material | Polyvinyl Chloride | |
| Minimum Operating Temperature | -40°C | |
| Conductor Type | Stranded | |
| Maximum Operating Temperature | 80°C | |
| Standards/Approvals | EN 50575, EN 13501-6, RoHS | |
| Voltage | 500V | |
| Fire Behaviour | Flame Retardant | |
| Conductor Material | Bare Copper | |
| Select all | ||
|---|---|---|
Brand Lapp | ||
Product Type Data Cable | ||
Cross Sectional Area 0.75 mm² | ||
Cable Length 100m | ||
Jacket Colour Grey | ||
Jacket Material Polyvinyl Chloride | ||
Minimum Operating Temperature -40°C | ||
Conductor Type Stranded | ||
Maximum Operating Temperature 80°C | ||
Standards/Approvals EN 50575, EN 13501-6, RoHS | ||
Voltage 500V | ||
Fire Behaviour Flame Retardant | ||
Conductor Material Bare Copper | ||
- COO (Country of Origin):
- CN
The Lapp UNITRONIC LIYCY 10X0,75 is a screened data cable for low frequency applications. The cable is designed for fixed installation and for conditional flexible use. It has 10 cores and 0.75 mm2 cross sectional area of the conductor. It has PVC sheath and is grey in colour.
For use in dry and damp interiors
Flame retardant
Cable is conform to the low voltage directive
Cable meets the substance specific requirements of RoHS
